Waterproof RS232 PCI Encrypting ATM Keyboard Pinpad
Sunson Tech SE8098C is an encrypting PIN pad(EPP) for indoor and outdoor use, offering manufacturers another form factor for integration. Optimized for use in self-service kiosks, ATMs and self-payment gas pumps, the ruggedized design of this EPP is built to withstand the most severe fraudulent attacks while complying with payment security standards on the back end.
For ATM applications, Sunson Tech offers an optional XFS Service provider for easy integration.
Mechanical Performance
| Key lifespan | More than 2 million operations |
| Key pressure | Numeric key:3.0N±0.3N Functional key:5.0N±1.0N Removal point:≥2.5N±0.4N |
| Key stroke | Not less than 0.4mm |
| Key fonts | Laser etching and durable ink, can be customized |
| IK protection level | IK08 |
| Waterproof level | IP65(key surface) |
| Panel size | 160mm*102.5mm*1.5mm |
| Net weight | 0.75kg |
Electrical Performance
| Interface | Standard USB2.0 interface |
| Input voltage | DC5.0V±5% |
| Power consumption | ≤0.5W(dynamic),≤0.2W(static) |
| Reliability | MTBF: >30,000H; MTTR: <30 min |
| Support OS | Windows XP, Windows 7 and Windows 10 (32 and 64bit) |
Main Function
| Algorithm standard | DES,Triple DES,RSA,SM2, SM3, SM4 |
| Function | PIN encryption,MAC operation, data encryption/decryption, remote key management |
| Standard conformed | ISO13491,ISO9564,IBM3624,ANSI X9.8,ANSI X9.9,ANSI X9.42,ANSI X9.19, ANSI,X9.24,ANSI X9.52 |
| Safety features | Water proof, dust proof, vandalism resistance, anti-drill, anti reveal, anti replacement etc |
| Self destroy function | All sensitive data will be automatically delete once illegal dismantle |
| Protection Capacity | Sensitive data is securely kept over 5 years when power off |
Applications
? Self-service terminals: such as E-bank terminal, ticket vendors, vendor, auto gas dispenser, etc.
Sunson Profile
FAQ
Q1: Can you customize the metal keyboard or keypad?
A1: Yes, we can customize language & layout for you freely.
If you have big order need customized size, surface etc., tailor made service is also available.
Q2: How long is the warranty for your products?
A2: The standard warranty is 1 year from the date of delivery, but can extended if extra cost paid.
Q3: Can you provide free sample?
A3: We can provide you sample for approval, but there is a sample charge, which can be returned when your order qty reaches a certain number.
Q4: What is EPP?
A4: EPP is short of Encrypted PIN Pad, an Encrypting PIN Pad is an apparatus for encrypting an identifier such as a PIN entered on a keypad. These are used in Automated teller machines or self-service kiosk to ensure that the unencrypted PIN is not stored or transmitted anywhere in the rest of the system and thus cannot be revealed accidentally or through manipulations of the system.
Q5: What kind of support can you provide on software development?
A5: We can provide you complete SDK for you to development software, we also have a strong engineers and customer service team to provide you technical support.
