floor deck machine roll forming machine deck floor machine
L/CT/T
5 ton Manual de-coiler | 1.Max width：1250㎜ 2.Max weight ：5T
|
Deck floor roll forming machine | 1. Matching material: colored armor plate with the bending intensity of Q195-235 .Material thickness: 0.8-1.2mm ,max 1.5mm 2. Power: 22kw 3. Forming speed: 8 m/min 4. The width of the plates:according to the drawings 5.the formed width:according to the drawings 6. Roll stations: Approx 28--32 7. Shaft Material and diameter: 45# steel, ￠85mm 8. Tolerance: +-1.5mm 9. Way of drive: chain driven 10. Controlling system: PLC 11. Voltage:depend on client 12. Material of forming rollers: 45# heat treatment and chromed. |
Cutting | 1.Cutting motion: The main machine automatically stops and then cutting. After the cutting, the main machine will automatically start. 2.Material of blade:Cr 12 with quenched treatment HRC58-62 3.Length measuring: Automatic length measuring 4.Tolerance of length: 10+/- 1.5mm |
