Air Source Ozone Generator Technical Parameters
Model | Ozone production | Feed gas flow | Ozone Concentration | Cooling water flow | Power consumption | Electronic Control Cabinet Dimension(mm) | Ozone discharge chamber Dimension (mm) |
| kg/h | Nm3/h | wt% | m3/h | Kwh/kgO3 | W D H | W D H | |
| POZBA-1K | 1 | 26-39 | 2-3 | 3-4 | 14-17 | 800x800x1800 | 900x800x1800 |
| POZBA-2K | 2 | 52-77 | 2-3 | 6-8 | 14-17 | 2000x900x1800 | 2100x900x1800 |
| POZBA-3K | 3 | 77-115 | 2-3 | 9-12 | 14-17 | 2000x900x1800 | 2100x1000x1900 |
| POZBA-4K | 4 | 105-155 | 2-3 | 12-16 | 14-17 | 2200x1000x2000 | 2100x1100x2000 |
| POZBA-5K | 5 | 130-190 | 2-3 | 15-20 | 14-17 | 3300x1100x2040 | 2200x1200x2100 |
| POZBA-6K | 6 | 155-230 | 2-3 | 18-24 | 14-17 | 3300x1100x2040 | 2200x1200x2100 |
| POZBA-8K | 8 | 205-310 | 2-3 | 24-32 | 14-17 | 3700x1200x2040 | 3800x1000x2100 |
| POZBA-10K | 10 | 260-390 | 2-3 | 30-40 | 14-17 | 4000x1200x2140 | 3800x1200x2100 |
| POZBA-15K | 15 | 390-580 | 2-3 | 45-60 | 14-17 | 4500x1200x2250 | 3900x1200x2100 |
| POZBA-20K | 20 | 515-755 | 2-3 | 60-80 | 14-17 | 5600x1200x2350 | 3900x1300x2300 |
| POZBA-25K | 25 | 640-960 | 2-3 | 75-100 | 14-17 | 5600x1200x2350 | 3900x1400x2400 |
| POZBA-30K | 30 | 775-1160 | 2-3 | 100-120 | 14-17 | 6000x1200x2350 | 3900x1500x2500 |
| POZBA-40K | 40 | 1030-1550 | 2-3 | 120-160 | 14-17 | 6200x1600x2250 | 4000x1800x2700 |
| POZBA-50K | 50 | 1290-2320 | 2-3 | 150-200 | 14-17 | 8500x1600x2350 | 4000x2000x2850 |
Oxygen Source Ozone Generator Technical Parameters
Model | Ozone production | Feed gas flow | Concentration | Cooling water flow | Power consumption | Electronic Control Cabinet Deimension(mm) | Ozone discharge chamber Dimension (mm) |
| kg/h | Nm3/h | wt% | m3/h | Kwh/kgO3 | W D H | W D H | |
| POZBO-1K | 1 | 7-9 | 8-10 | 1.5-2 | 14-17 | 700x800x1800 | 800x800x1800 |
| POZBO-2K | 2 | 14-18 | 8-10 | 3-4 | 14-17 | 800x800x1800 | 900x800x1800 |
| POZBO-3K | 3 | 21-26 | 8-10 | 4.5-6 | 14-17 | 1200x1000x1900 | 800x1000x1900 |
| POZBO-4K | 4 | 28-39 | 8-10 | 6-8 | 14-17 | 2000x900x1800 | 2100x900x1800 |
| POZBO-5K | 5 | 34-43 | 8-10 | 7.5-10 | 14-17 | 2000x900x1800 | 2100x1000x1900 |
| POZBO-6K | 6 | 41-52 | 8-10 | 9-12 | 14-17 | 2000x900x1800 | 2100x1000x1900 |
| POZBO-8K | 8 | 55-69 | 8-10 | 12-16 | 14-17 | 2200x1000x2000 | 2100x1100x2000 |
| POZBO-10K | 10 | 68-86 | 8-10 | 15-20 | 14-17 | 3300x1100x2040 | 2200x1200x2100 |
| POZBO-15K | 15 | 102-128 | 8-10 | 17.5-30 | 14-17 | 3700x1200x2040 | 3800x1000x2100 |
| POZBO-20K | 20 | 136-171 | 8-10 | 30-40 | 14-17 | 4000x1200x2140 | 3800x1100x2100 |
| POZBO-25K | 25 | 170-210 | 8-10 | 36-50 | 14-17 | 4000x1200x2140 | 3800x1200x2100 |
| POZBO-30K | 30 | 203-256 | 8-10 | 45-60 | 14-17 | 4500x1200x2250 | 3900x1200x2100 |
| POZBO-40K | 40 | 271-341 | 8-10 | 60-80 | 14-17 | 5600x1200x2350 | 3900x1300x2300 |
| POZBO-50K | 50 | 339-426 | 8-10 | 75-100 | 14-17 | 5600x1200x2350 | 3900x1400x2400 |
| POZBO-60K | 60 | 406-511 | 8-10 | 80-120 | 14-17 | 6000x1200x2350 | 3900x1500x2500 |
| POZBO-70K | 70 | 485-625 | 8-10 | 105-140 | 14-17 | 6200x1600x2250 | 3900x1600x2600 |
| POZBO-80K | 80 | 542-681 | 8-10 | 120-160 | 14-17 | 6200x1600x2250 | 4000x1800x2700 |
| POZBO-100K | 100 | 677-852 | 8-10 | 150-200 | 14-17 | 8500x1600x2350 | 4000x2000x2850 |
Note
1. Power consumption is based on different ozone concentration and cooling water conditions.
2. Customerize for higher ozone concentration ozone generator.
About us
Qingdao Wingoal Trade Co., Ltd. is the subsidiary of Shandong Pioneer Environmental Protection Technology Co.,Ltd,. PIONEER is a well-known professional Ozone Generator System manufacturer in China. We mainly offer ozone generators (air source and oxygen source) in wide range applications especially in water-treatment. With R&D centers and international advanced ozone generator manufacturing technology, PIONEER products have exquisite structure, stable performance, simple operation and convenient maintenance. In different fields, Pioneer designs and offers complete ozone generator system solutions according to customers' actual situation and requirements. Pioneer products have exported to more than 20 countries around the world and got recognition from customers.
Pioneer will as always work hard to supply premium products and devote to environmental protection industry. Contact us today for your needs!
Our Core Technology
Special glass tube discharge chamber(Patent No ZL2011 2 0385785) adopts double air gap discharge technology, high quality glass medium and matching dedicated power supply, fully exerts the efficiency of corona discharge to produce ozone, ensuring large output, high concentration and lower power consumption.
The high voltage transformer converts the alternating current output from the inerter circuit into high voltage electricity suitable for generation of ozone by generating a dielectric barrier discharge in the chamber discharge body. In order to match the capacitive characteristics of the occurrence of the discharge of the chamber discharge body, the requirements of its parameters are different from those of ordinary transformers.
The ozone generator control system is independently developed by the company to control the normal operation of the ozone generator power supply, and has anti-jamming, load short circuit protection, high operating temperature protection, with industry leading level, high operation reliability.
Our Products advantage
All in one equipment, easy to operate
Over temperature protection, over-current protection, and over-voltage abnormality monitoring.
Ozone leakage alarm, operation fault alarm monitoring
Supply full set of auxiliary equipment, including air compressor, gas storage tank, filter, freezing dryer, adsorption dryer etc.
Use special stainless steel tube for discharge chamber
With SIEMENS PLC touch screen automatic control system, users can achieve monitoring, control, switching, setting, report, alarm, cycle start-up, emergency shutdown etc. functions.
