Business Type: Manufacturer
Main Products:Prefab HousesContainer HousesResidentialOffice RoomDormitory HousesSteel BuildingsHospital ModularHotel ModularContainer ModularMedical Modular
ID:20102626374
Category: Construction & Decoration Building Structural Material
MOQ:1.00 Piece(s)
flat pack new home flat pack modern homeflat pack popular home flat pack medium home flat pack luxury home flat pack affordable home flat pack low cost home flat pack cheap home flat pack beautiful home flat pack camp home
L/CT/TD/PWestern UnionPaypalMoney GramOthers
| BREAK DOWN QUOTATION SHEET | ||||
| No. | NAME | DESCRIPTION | UNIT | THEORY QTY |
| LGS Structure | ||||
| 1 | steel structure | ㎡ | 243 | |
| 2 | fittings | set | 243 | |
| Wall System | ||||
| 1 | External wall OSB board | 1220*2440*9mm | ㎡ | 252.1 |
| 2 | External wall unidirectional breath paper | ㎡ | 308.7 | |
| 3 | External wall wooden support | 30*40*3000mm | m | 756.3 |
| 4 | External wall metal carved board | 381*3800*16mm +381*4500*16mm | ㎡ | 252.1 |
| 5 | Internal wall OSB board | 1220*2440*9mm | ㎡ | 402.6 |
| 6 | Internal wall gypsum board | 1200*2400*9mm | ㎡ | 402.6 |
| 7 | Wet district fiber cement board | 1220*2440*10mm | ㎡ | 116.85 |
| Insulation System | ||||
| 1 | Glasswool Insulation | T75mm，12㎡/roll 16Kg/m3 | ㎡ | 385.775 |
| 2 | Glasswool insulation(under roof) | T75mm，12㎡/roll 16Kg/m3 | ㎡ | 165 |
| 3 | External wall XPS board | 1200*600*40mm | ㎡ | 252.1 |
| Floor System | ||||
| 1 | Floor surface OSB | 1220*2440*18mm | ㎡ | 110 |
| 2 | Floor self-paste waterproof coil | T1.5mm，-15℃，20㎡/roll | ㎡ | 110 |
| 3 | Floor concrete cushion | C25 concrete | ㎡ | 110 |
| Roof System | ||||
| 1 | Roof OSB board | 1220*2440*12mm | ㎡ | 165 |
| 2 | self-paste waterproof coil | T1.5mm，-15℃，20㎡/roll | ㎡ | 165 |
| 3 | Roof tile | asphalt tile | ㎡ | 165 |
| 4 | Roof ridge tile | asphalt tile | m | 27.9 |
| 5 | Roof eaves pvc molding | 6m/pc | m | 63.5 |
| 6 | PVC closing strip | 4m/pc | m | 63.5 |
| 7 | Metal carved board under roof eaves | 381*3800*16mm | ㎡ | 38.1 |
| Door & Window | ||||
| 1 | Alumunium window | ㎡ | 56.6 | |
| 2 | Interior door | ㎡ | 9.6 | |
| 3 | Accessories for door sill/windowsill | 1220*2440*10mm | m | 172 |
| Water&Electric System | ||||
| 1 | Water Pipes | ㎡ | 243 | |
| 2 | Electric system | Include weak current,exclude socket/switch/light,etc | ㎡ | 243 |
| Decoration Accessories System | ㎡ | 243 | ||
| Hardware Accessories System | ㎡ | 243 | ||
