Ozone Generator System for Swimming Pool
Ozone Technology: a compact ozone system
The
compact ozone range is designed for disinfection of private and hotel
sized swimming pools. Ozone provides effective treatment against
chlorine resistant micro-organisms and significantly improves water
clarity.
PSOZON
series is a high-performance ozone generator system for swimming pools.
The utility model has the advantages of ingenious structure, convenient
installation, simple operation, high safety and low demand for cooling
water. There are many advantages, such as new technology, high
performance and so on. Complete set of equipment, opening the machine
can run.
Specification
Model | Ozone production | Cooling water flow | Power consumption | Interface diameter | Dimension(mm) | |
| g/h | m3/h | Kwh | cooling water | ozone output | W D H | |
| PSOZN-10 | 10 | 0.03 | 0.4 | R1/2" | R1/2" | 4000x300x1000 |
| PSOZN-20 | 20 | 0.05 | 0.5 | R1/2" | R1/2" | 600x450x1400 |
| PSOZN-40 | 40 | 0.08 | 0.9 | R1/2" | R1/2" | 600x450x1400 |
| PSOZN-80 | 80 | 0.15 | 1.2 | R1/2" | R1/2" | 800x600x1700 |
| PSOZN-120 | 120 | 0.20 | 2.2 | R1/2" | R1/2" | 1200x600x1700 |
| PSOZN-150 | 150 | 0.30 | 2.6 | R1/2" | R1/2" | 1200x600x1700 |
| PSOZN-200 | 200 | 0.40 | 3.5 | R1/2" | R1/2" | 1600x600x1700 |
| PSOZN-250 | 250 | 0.50 | 4.0 | R1/2" | R1/2" | 1600x800x2000 |
| PSOZN-300 | 300 | 0.60 | 5.0 | R1/2" | R1/2" | 1600x800x2000 |
| PSOZN-400 | 400 | 0.80 | 7.0 | R1/2" | R1/2" | 1800x800x2000 |
| PSOZN-500 | 500 | 1.00 | 8.0 | R1/2" | R1/2" | 1800x800x2000 |
Note:
1. Power consumption is based on different ozone concentration and cooling water conditions.
2. Customerize for higher ozone concentration ozone generator.
Ozone Knowledge
For
a long time, in medical and health, pharmaceutical, food processing and
other aspects, disinfection and sterilization of water and air has been
used ultraviolet radiation, chemical fumigation, spraying and other
methods, there are many defects in the use. The emergence of ozone
sterilization and disinfection products provides a fast, efficient, safe
and reliable disinfection method, which is the ideal substitute for
traditional disinfection equipment and will inevitably be widely used.
Ozone
O3 is the oxygen O2 isomorphism, the composition element is the same,
the composition form is different, the property is very different.
Ozone
is gaseous at room temperature, colorless and grassy at low
concentration, and soluble in water. It is known as one of the strongest
oxidants. The chemical properties of ozone are more active and have
strong oxidation ability. When met with bacteria and harmful chemicals
(such as formaldehyde, benzene, ammonia), immediately produce oxidation
reaction, so as to play the function of sterilization and disinfection,
mildew, taste, decomposition of harmful gases and so on. Ozone is
unstable, and its aerobic O2 changes, reducing it to O2, within a few
minutes, so it is free of pollution and residue. It is so far the world
recognized that food and beverage direct disinfection of the only
substance!
The
high concentration ozone generator produced by our company is a kind of
high concentration ozone generator equipment dedicated to air
purification and water treatment. It adopts the latest ozone generating
device and many kinds of protection function circuits inside, and has
excellent performance and extremely long working life.
Advantage 1. Strong
sterilization and fast speed. Ozone kills Escherichia coli, hundreds of
times faster than chlorine, and has an effective killing effect on
viruses and bacteria in prokaryotes.
Advantage 2. Swimming
pool ozone generator can prevent the accumulation of organic dirt, can
improve water quality, remove color, kill pathogenic microorganisms, and
the treated water can effectively prevent the spread of infectious
diseases.
Advantage 3. Swimming
pool ozone generator can effectively reduce pollutants in the water,
reduce the formation of by-products (monochloramine, dichloramine,
trichloramine, chloroform, etc.) after the chlorination of organic
pollutants and protect swimmers healthy.
Advantage 4. During
the treatment process, the residual ozone in the water returning to the
swimming pool will not exceed the safety limit, and the air can be
sterilized and purified to make the indoor air fresh and comfortable.
Our Products advantage
1. All in one equipment, easy to operate
2. Over temperature protection, over-current protection, and over-voltage abnormality monitoring.
3. Ozone leakage alarm, operation fault alarm monitoring
4. Supply full set of auxiliary equipment, including air compressor, gas storage tank, filter, freezing dryer, adsorption dryer etc.
5. Use special stainless steel tube for discharge chamber
6. With SIEMENS PLC touch screen automatic control system, users can achieve monitoring, control, switching, setting, report, alarm, cycle start-up, emergency shutdown etc. functions.
Why Choose Us?
1. EXPERIENCE :11 years focus on ozone generator R&D and manufacture,service of more than 1000 customers.
2. 30000 square meter factory area
3. Core patent technology and authorized certifications
4. Strict quality control to ensure safe and reliable products
5.Service: 24 hours online service,life-long maintenance
6.Professional overseas sales team, supply prompt response
