swimming pool heat pump heaterheat pump chillerair to water chiller
T/T
heating capacity 12kW/19kW/35kW/45kW
R410A refrigerant
380V~440V 50Hz power supply
Best way connect with the solar water heater to together heating the swimming pool, it's running at the lowest cost.
12kw suit for 27.43cube meter pool
19kw suit for 43.42cube meter pool
35kw suit for 79.85 cube meter pool
45kw suit for 102.82 cube meter pool
The swimming pool heat pump unit uses heat pump technology to get heat energy from the air and heat the water, and the water and electricity are completely separated. It has no open fire, and produce no harmful gas. It is safe and environment-friendly. Compared with the hot water equipment that uses other energy sources, it can save 65 to 80% of the operating expenses. All the heat exchangers are made of titanium alloy, which can help resist the chloride ion corrosion in water and is harmless to the human body.
Product Application Place: It is suitable for heating the indoor and outdoor swimming pools of hotels, bathrooms, families, etc.
| Swimming pool Heat Pump water heater | |||||
| Model | KFCRS-12II | KFCRS-19II | KFCRS-35II | KFCRS-45II | |
| Horse Power | HP | 3 | 5 | 10 | 12 |
| Heating Capacity | kW | 12 | 19 | 35 | 45 |
| Btu/h | 40900 | 64800 | 119400 | 153540 | |
| Rated Input Power | kW | 2.4 | 3.7 | 6.9 | 8.9 |
| Rated Input Current | A | 4.3 | 6.6 | 12.3 | 15.9 |
| Max Input Power | kW | 2.6 | 4.8 | 9 | 11.6 |
| Max Input Current | A | 5.6 | 8.6 | 16 | 20.7 |
| COP | W/W | 5 | 5.09 | 5.07 | 5.07 |
| Electric Shock Protection Grade | I | ||||
| Waterproof Grade | IPX4 | ||||
| Operating Ambient Temperature | -10℃~45℃ | ||||
| Power Supply | 380V/3PH/ 50Hz | ||||
| Produce Hot Water Temperature | 20~45℃ | ||||
| Hot water yield | L/h | 793 | 1256 | 2314 | 2980 |
| Inlet/Outlet Pipe Size | DN | DN40 | DN50 | ||
| Water Side Pressure Loose | mPa | ≤70 | |||
| Water Pump Head | m | 8 | |||
| Water Pump Flow | m3 | ＞5.2 | ＞8.2 | ＞15.1 | ＞19.4 |
| Discharge Side Over Pressure | 4.4mPa | ||||
| Sunction Side Lower Pressure | 0.05mPa | ||||
| Compressor / QTY | Scroll | Copeland/1 | Copeland/2 | ||
| Heat exchanger | Titanium high efficient tube in shell heat exchanger | ||||
| Refrigerant | R410A | 1900g | 2800g | 2×2800g | 2×3000g |
| Noise | dB(A) | 56 | 62 | 64 | 66 |
| Unit Dimension | mm | 680×680×860 | 760×760×965 | 1406×765×1050 | |
| Package Size | mm | 740×740×900 | 840×840×1100 | 1500×830×1200 | |
| Weight ( NW/GW) | kg | 100 | 160 | 293 | 379 |
| Test Condition :Ambient temp.(DB/WB):20℃/15℃,Input/output water temp.=15℃/28℃ Note: indoor swimming pool with a circulation rate of the basic unit routine follow: 1HP: 10 tons (without pool refill water) | |||||
