Die Cutting Machinecreasing machine Flat bed die cutting machineMY 1300MY 1500Die cutterAutomatic die cutting machinemanual die cutting machine die cutter stripping carton machine
T/T
The machine has two motion states: manual and automatic. When the paper is in good condition, the automatic state can be adopted to give full play to the speed advantage of the machine. When the paper is in a poor state, manual mode can be used, which can easily switch modes. When in manual mode, the space can be completely released, which is fully suitable for workers to operate.
The powerful four-suction and four-feed feeder can adjust the suction angle according to the deformation of the paper, and the air-out paper separation device facilitates paper separation.
Mainly used for cardboard, map, E, B corrugated paper.
Overload protection mechanism, in case of accidental overload, the die-cutting plate frame which is separated actively can effectively prevent the die-cutting plate from sagging and falling off
The main chain (Germany) adopts a heavy-duty high-precision transmission chain, with minimal chain yield error, high tensile strength and abrasion resistance.
The electric control system adopts PLC control which is equipped with various safety protection devices. When a fault occurs, it will alarm by sound and light, and automatically stop, which truly protects the safety of people and machines.
The timing and quantitative automatic oil supply system ensures that other running parts of the machine are fully lubricated and have a long service life.
Stripping part can option.
Item | Parameters | ||
Model型号 | MY-1300 | MY-1500 | MY-1650 |
Max paper transmitting size (mm) 最大传送纸面积 | 1300X930 | 1500X1100
| 1650X1200 |
Min paper transmitting size(mm) 最小传送纸面积 | 500X450 | 550X500
| 600X550 |
Max die-cutting size（mm) 最大模切面积 | 1280X910 | 1480X980 | 1640X1180 |
Min gripper size（mm) 最小咬口尺寸 | 8mm | 8mm | 8mm |
Max die-cutting pressure 最大模切压力 | 350N/cm2 | 350N/cm2 | 350N/cm2 |
Max die-cutting speed 最高机械速度 | 5500 sheets/h | 5000 sheets/h | 5000 sheets/h |
Max feeding pile height 最大进料高度 | 1200mm | 1200mm | 1200mm |
Min feeding pile height 最小进料高度 | 1200mm | 1200mm | 1200mm |
Main motor power 主电机功率 | 11kw | 15kw | 17kw |
Total weight 总重量 | 17T | 19T | 22T |
Overall size 外形尺寸 | 6500*2300*2300 | 6850*2450*2300 | 7200*2600*2300 |
