Business Type: Manufacturer
Main Products:Electric Valve ActuatorPneumatic Valve ActuatorBall ValvesButterfly ValvesAngle Seat ValveDiaphragm Valves
ID:20103028985
Category: Manufacturing & Processing Machinery Valves & Pumps & Compressors
MOQ:1.00 Piece(s)
Ball ValvesPneumatic Ball ValvePneumatic ValvesFlanged Ball ValvesStainless Steel Ball Valves3PCS Ball Valves
L/CT/TWestern UnionMoney GramOthers
Pneumatic Actuated Stainless Steel Ball Valve Features
1. Flanged Ball Valve/Welded Ball Valve/Threaded Ball Valve/Clamp Ball Valve
2. Electro and Mechanical Polishing
3. Sealing Material: PTFE, NBR, EPDM, FPM
4. Manufacture Standard: GB, DIN, ISO, SMS
5. Zero Leakage
Pneumatic Actuated Stainless Steel Ball Valve Specifications
1). Nominal Diameter: DN15-300
2). Pressure Range: 1.6-6.4 Mpa
3). Medium Temp.: -10°C~+180°C
4). Ambient Temp.: -10°C~+60°C
5). Valve Body Material: SS304, SS316, WCB
6). Sealing Material: PTFE
7). Actuator Cover: Aluminum Alloy
8). Operating Pressure: 3-8bar
9). Type: Double-acting, single-acting
10). Standard: ANSI, DIN, JIS
11). Connection: Flanged
| Brand: | KST/OEM |
| Applicable Media: | Water, Oil, Gas, Nitric Acid, Acetic Acid |
| Certification: | CE/API/DNV/FDA/ISO9001-2008 |
| Sample Testing: | One Sample for free( Under $10),Freight Collect |
| Packing: | Plastic Bag, Carton & Plywood Case/According to customers' requirement. |
| Payment: | T/T, L/C, D/P, Western Union, Paypal |
| Port: | NINGBO/SHANGHAI, Customers' Request |
| Delivery Time: | Within 35days after receiving T/T deposit Payment |
| Term of Delivery: | FOB/CNF/CIF, Customers' Request |
