Pneumatic Operation Wafer Butterfly Valve Specifications
1). Pressure Range: ≤ 1.6Mpa
2). Flanged Connection: DIN250-PN10/16-ANSI 150LB
3). Nominal Diameter: DN40-DN200
4). Application: Petroleum, ChemicalIndustry, Food, Medicine, Energy etc.
5). Medium Temp.: -79o C-+180o C (it depends on sealing material)
6). Dimension: GB/T 12221 J1 Series
ISO 5752 Short Series 20
BS 5155 Water Short/Medium
DIN 3202 Part 3 Series K1
7). Top Flange: ISO 5211
8). Body: Gray Cast Iron, Ductile Cast Iron
9). Disc: Ductile Cast Iron, Stainless Steel, Brass Alloy ect.
10). Stem: Stainless Steel
11). Seat: PTFE, PFA, F46, UHMWPE ect.
12). Operation: Handle, Worm wheel, Electrical, Pneumatic, Hydraulic Actuator, Electro-hydraulic Linkage
13). Leakage Level: RPTEA EA 12266-2 (Zero Leak)
| Brand: | KST/OEM |
| Applicable Media: | Water, Oil, Gas, Nitric Acid, Acetic Acid |
| Certification: | CE/API/DNV/FDA/ISO9001-2008 |
| Sample Testing: | One Sample for free( Under $10),Freight Collect |
| Packing: | Plastic Bag, Carton & Plywood Case/According to customers' requirement. |
| Payment: | T/T, L/C, D/P, Western Union, Paypal |
| Port: | NINGBO/SHANGHAI, Customers' Request |
| Delivery Time: | Within 35days after receiving T/T deposit Payment |
| Term of Delivery: | FOB/CNF/CIF, Customers' Request |
