Flat bed die cutting machineManual die cutting machinedie cutting machinesemi auto die cutting machinedie cutcreasing machineTongbao die cutting machinecarton machineMY 1300flat bed
T/T
Manual paper can better adapt to wrap, convenient paper, and easy to reach the designated position.
To paper automatic upgrade interval can be set with the paper, the operation is convenient.
Diao paper tooth diameter size can be adjusted with thick paper, bite paper firm.
High strength hard aluminum alloy tooth row of teeth type, Diao paper smoothly, effectively prevent the tooth row of fibrillation, before and after the tooth row position increases the adjustable device.
The main transmission adopts a pneumatic clutch, frequency modulation motor, smooth braking rapidly.
Die-cutting steel with high hardness, high elasticity and high manganese alloy spring steel material, durable.
The electric system adopts a PLC program controller, man-machine interface touch screen, monitor and other advanced control devices, dynamic monitoring of the various parts of the machine.
To paper, die-cutting, paper and other parts to install multiple photoelectric detection switch, effectively ensure the safety of the whole process run smoothly.
Die-cutting exhaust function, waste box pre-loaded with machines, die-cutting plate and frame flip preset rack(Optional)
型号type | MY-1300 | MY-1500 | MY-1650 |
最大输纸尺寸 Maximum paper size（mm） | 1300 x 930 | 1500x1100 | 1650x1200 |
最小输纸尺寸 /Minimum paper size（mm) | 500 x450 | 550 x500 | 600x550 |
最大模切尺寸 /Maximum die cutting size： | 1280 x910mm | 1480x1080 | 1630x1180 |
最大模切压力/Maximum die cutting pressure： | 350T | 350T | 350T |
可加工纸张厚度/Processable paper thickness： | ≤8mm
| ≤8mm
| ≤8mm
|
钢板厚度 /Steel plate thickness： | 7mm | 7mm | 7mm |
最高速度/ top speed： | 5500s/h | 5000s/h | 5000s/h |
额定功率/ Rated power： | 14kw | 15w | 17kw |
整机重量/ Total weight： | 13T | 15T | 18T |
整机外形尺寸/ Overall dimensions： | 3700x2300x2300 | 4300x2450x2300 | 5000x2600x2300 |
