Flat bed die cutting machineautomatic die cutting machinedie cutting machinecarton machinecreasing machineMY 1300Tongbao die-cutting machine die cutlead edge feeding die cutting die cutting stripping
T/T
The use of the patented lead edge feeding structure can effectively prevent and reduce damage to the paper printing surface.
The machine is mainly used for corrugated paper of more than 3mm.
The main chain (Germany) adopts heavy load and high precision transmission chain, with very small production error, high tensile strength and wear resistance.
There are two ways of receiving paper, such as towing board and trolley, which greatly improve the working efficiency. It has a photoelectric detection device, safe and reliable, and ensures the fast and steady receiving of paper.
It has an overload protection mechanism, to achieve accidental overload, active separation of the die-cutting board frame can effectively prevent the die-cutting board from sagging and fall off.
Pneumatic lock plate mechanism adopts imported cylinder, stable performance, convenient and fast operation.
The electric control system is controlled by PLC and equipped with various safety protection devices, which can give audible and visual alarm in case of failure and shut down automatically, truly guaranteeing the man-machine safety.
The timing and quantitative automatic oil supply system can ensure the full lubrication of other moving parts of the machine and have a long life.
The stripping part(optional).
MY1300 | MY1500 | MY1650 | |
最大输纸尺寸The maximum feed size | 1300×930 | 1500×1100 | 1650x1200 |
最小输纸尺寸 Minimum feed size | 450×400 | 500×450 | 550×500 |
最大模切尺寸 Maximum die cutting size | 1280×910 | 1480×1080 | 1630×1180 |
模切精度 Die cutting accuracy | ≤±0.50mm | ≤±0.50mm | ≤±0.50mm |
最高机械速度 mechanical speed | 5500S/H | 5500S/H | 5000S/H |
工作压力 working pressure | 350T | 350T | 350T |
主电机功率 Main motor power | 11kw | 11kw | 15kw |
总功率 total power
| 38kw | 38kw | 38kw |
机械净尺寸 The mechanical net size | 9100×2300×2300 | 11000×2450×2300 | 13000×2600×2300 |
整机重量 machine weight | 17T | 19T | 22T |
