Bottom Printing Flexo Printer Slotter Folder Gluer Inline

Automatic Control Bottom Printing Flexo Printer Slotter Folder Gluer Inline High Speed

◆ High precision transfer structure with ceramic vacuum transfer wheel,good registration accuracy.

◆ Suitable for diversified kinds of size of carton making.

◆ Finished carton fishtail +/-1MM

◆ Creasing-slotting unit, prevent creasing line from bursting, better folding.

◆ Counter ejector with down stacking.

◆ Choose international brand electric components and transfer bearings,pass CE certification

Technologic parameter

Features

BOTTOM PRINTING PRINTER

FEEDING SECTION
? Lead edge feeder with accurate feeding for all flutes and warped sheets.
? Available for skip feed and feed interrupt.
? Auto zero-set for feeding position with one push button.
? Non back- lash transmission gear system.
? All gap adjustment via eccentric device with PLC control.
? Frequency inverter drive with variable suction control.
? Dust vacuum cleaner for sheet.

PRINTING SECTION
? Bottom print.
? Highly accurate printing registration.
? Laser engraved ceramic anilox roll.
? Rubber roll system as standard.
? Auto zero- set for printing position with one push button.
? Optional- Ink chamber blade device with programming auto wash ink system.
? Optional- Vacuum transfer device for sheet..

SLOTTER CREASER SECTION
? Dual slotting shafts for leading knives and trailing knives.
? Separate shaft for pre-creaser and creaser ensure sufficient crushing and creasing.
? Auto zero- set for slotting knife with one push button.
? Standard digital counter with pre- set one order, auto positioning of slotting knives
for box panel dimension.
? Optional- Single slotting shaft for both leading and trailing knives.

DIE CUTTER SECTION
? Heavy duty die cutting drum
? Hydraulic oscillation movement for anvil drum to prolong anvil life time.
? Auto zero- set for die cutting position with one push button.
? Optional- Anvil trimming and anvil drum synchronized drive.

FOLDER GLUER

FOLDER GLUER (UFGT)
? Bottom suction belt with up folding for stable performance.
? Use PU crushless wheel holding sheet in folding section.
? Independent drive for upper bottom belt speed adjustment through touch screen control.
? Side guiding wheel tracking box folded edge for accurate flap gap.
? Frequency inverter drive control system.

COUNTER EJECTOR (UFGT)
? Full integrated construction with HMI control device.
? Quick positioning via AC servo control.
? Top loading device for receiving and stacking boxes.
? Suitable for die cutting box use.
? Accurate counting quantity of boxes and eject bundle of boxes.
? Upper holding wheel to deliver bundle of boxes without collapse.
? Full closed unit for safety operation.

BUNDLER(OPTION)

1 Connect with folder gluer

2 Can move in lateral direction

3 Pneumatic flapping structure make the carton tidy and easy to bundle

4 Special string mouth design, makes the string output smooth and never broken

5 Easy to maintain and operate

6 Bundling speed 15-20 bundles per minute.
