Automatic Top Printing 3 Color Carton Flexo Printer Slotter Die Cutter
Automatic Top Printing 3 Color Carton Flexo Printer Slotter Die Cutter used for corrugated carton box making companies, 1) the machine has roller transfer printing unit and vacuum transfer printing unit for option .2) rubber roller ink distribution and Doctor blade chamber ink distribution for option. 3)All the rollers, gears and main parts undergoes precise treatment to make sure running stable and printing precise.4)easy to operate and maintain.5)Speed:180-350pcs/min according to different cardboard size.
Technologic parameter
| Model | KC-H618 | KC-H 920 | KC-H1224 | KC-H1628 | KC-H1632 |
| Max feeding size | 600*1900mm | 900*2100mm | 1200*2500mm | 1600*2900mm | 1600*3300mm |
| Min feeding size | 220*600mm | 300*650mm | 400*720mm | 450*750mm | 450*750mm |
| Max printing size | 550*1800mm | 880*1000mm | 1150*2400mm | 1550*2800mm | 1550*3200mm |
| Skip feeding size | 800*1900mm | 1100*2100mm | 1400*2500mm | 1800*2900mm | 1800*3300mm |
| Max speed | 350pcs/min | 300pcs/min | 250pcs/min | 180pcs/min | 180pcs/min |
| Registering | +/-0.5mm | +/-0.5mm | +/-0.5mm | +/-0.5mm | +/-0.5mm |
| Min slotting gap | 240*60*240*60mm | 250*70*250*70m | 270*80*260*80mm | 280*100*280*100mm | 280*100*280*100mm |
| Slotting precise | +/-1.5mm | +/-1.5mm | +/-1.5mm | +/-1.5mm | +/-1.5mm |
| Die cutting precise | +/-1.5mm | +/-1.5mm | +/-1.5mm | +/-1.5mm | +/-1.5mm |
Feeder unit
1 Sun alike lead feeder makes cardboard feeding easily and stable, all the baffles adjusted by electric control
2 Dedust system help remove the dust of cardboard surface to make the printing better
3 The air volume adjusted by manual according to different cardboard
4 All the roller intervals are manual or electric control
5 Flap structure installed
6 Alarm will ring when close or open the unit
Printer unit
1 Top printing
2 Roller transfer or vacuum transfer for option
3 Doctor blade chamber or rubber roller ink distribution for option
4 Ceramic anilox roller or steel anilox roller for option
5 Rachet wheel fix printing plate
6 Rollers intervals adjusted by manual or electric control
7 Automatic reposition after washing the printing plate during printing
9 Ink shortage alarm installed
10 Automatic ink washing system for option
11 All the rollers undergoes balance treament, grinded surface and plated with rigid chrome
Slotter unit
1 Precreasing wheel, creasing wheel and second creasing wheel make the creasing line formed well
2 Slotting holder moving via screw axle and linear guide rail
3 Single or double shaft slotting structure for option
4 Rollers interval adjusted by manual or electric control
5 Die cutting hole installed for option
6 Slotting knife moving adjusted by PLC control
7 9Crsi and SKD slotting knife for option
Die cutting unit
1 Anvil trimming knife Installed for anvil cover treatment
2 Side to side oscillation of anvil drum 50mm
3 Anvil cover brand are Maxdura, Depak or CUE for option
4 Rollers interval adjusted by manual or electric control
5 Slotting knives can be installed for option
Stacker
1 Max stacking height 1600mm
2 Chain driving or hydraulic driving for option
3 Safety device installed to avoid the collection cabinet drop suddenly
4 Good quality convey belt for long time service
5 Can combined with vibration
