4x2 HOWO Cargo Truck

4x2   HOWO Cargo Truck

Key Performance

266 HP Engine/290HP Engine

Dimension of van:   5600(L)x2400(W)x2000(H)., height of van is customized.

Thickness of van floor:3mm, thickness   of van side: 1.5mm, it’s also customized.

Double doors in the rear, one door at the side.   Double doors at the side is customized.

With interior light, with marker light, with   protective bracket

Performance

Gross weight

16000 Kg

Chassis dead weight

7800 Kg

Wheel base

4600mm

Overall dimension

8300×2496×3048mm

Front overhang/Rear overhang

1500/2200

Front wheel track

2022

Rear wheel track

1830

Approach/Departure angle

16/26°

Max. driving speed

111Km

Fuel consumption(L/100km)

26

Engine

Make: SINOTRUK

Engine model: : WD615.62, Euro II emission   standard

Maximum output: 266hp(196Kw) at 2200 rpm according   to DIN

Maximum torque: 1100Nm at 1100~1600 rpm

4 stroke direct injection diesel engine,6 cylinder   in-line with water cooling, turbo-charging & inter cooling

Bore: 126mm; Stroke: 130mm;

Displacement: 9.726L; Compression ratio: 17:1

Specific fuel consumption: ≤193g/kWh;

Cooling system filling quantity (long-term filling):   40L

Option:

Thermostat with 71 °C opening begin

Silicon oil fan

Transmission

HW13710CL, 10 forward and 2 reverse. With HW70 power   takeoff

Clutch

430C Type, famous brand.

Driving axle

MCY13. Central single stage reduction, welded and stamped   axle housing

Load capacity: 13ton.   Ratio: 4.11

Front axle

HF7 drum brakes, load capacity: 7ton

Steering box

ZF8198 hydraulic steering with power assistance

Cab

SINOTRUK HW70 Standard cab, left hand driving , with   air conditioner, single bunk, new type seat, adjustable steering wheel ,EURO   new type heating & ventilating system, German VDO instruments, safety   belts, exterior sun visor, stereo radio/cassette recorder, right hand driving   for optional. 4-point support fully floating suspension with shock absorber.

Air conditioner

Yes

Tire

295/80R22.5, 11.00R20 for optional.

Chassis

Frame: U-profile parallel ladder type with section   of 300×80×8 mm and reinforced sub frame,

With one spare wheel

Rear spring: 10pcs, front spring:6pcs

Remarks

Exhaust pipe up

Yes, optional

Alert sound when back up

Yes, optional

Enhanced backboard beam

Yes, optional

Alert light

Yes, optional
