Concrete Mixer: 9M3

Cabin

Driving type

6×4

HOWO Standard   cab

Vehicle main Dimensions

Overall   dimensions (L×W×H)mm

9040×2496×3850

Wheel base (mm)

3225×1350

Wheel track   (front/rear) (mm)

2041/1850

Approach/Departure   angle(°)

16/32

Weight in KGS

Tare Weight

12800

Loading Capacity

12070

Front axles   loading capacity

7000

Rear axles   loading capacity

2×9000

Max.driving speed (km/h)

90

Engine

Brand

SINOTRUK

Type

4-stroke direct   injection,6-cylinder in-line with water cooking, turbo-charging and   inter-cooking

Displacement (L)

9.726

Horse Power   (HP)/(KPM)

336hp

Max.Torque/(KMP)

1160Nm/1100-1600RPM

Emission   standard

Euro II

Gearbox

HW19710, 10 forward, 2 reverse

Clutch

Reinforced   diaphragm clutch, diameter 420mm

Steering Gear

ZF power   steering, model ZF8118, hydraulic steering with power assistance

Fuel tank (L)

300

Tire

12.00R20,Optional   12.00R22.5,12.00-20 etc

Mixer Body

Volume

M3

9M3（10/12m3for optional）

5300×2300×1300

Body Thickness

mm

High tensile   strength steel

6mm

Gear box

Italy made   imported

 BONFILTOLT

Motor

Italy made   imported

 BONFILTOLT

Pump

Italy made   imported

 BONFILTOLT
