6x4 HOWO Dump Truck

6x4 Howo Dump Truck

Key Performance

Driving speed(km/h):

Max. Loading Capacity:

336Hp/371Hp engine for optional

HW19710, 10 gears transmission

With one berth

75KM/h, 85KM/h for optional.

28000KG

HW19710 Gear box with

Engine

Make: SINOTRUK

Engine model: WD615.47, Euro II   emission standard

4 stroke direct injection diesel   engine

6 cylinder in-line with water   cooling, turbo-charging & intercooling

Maximum output: 371hp(273Kw) at 2200   rpm according to DIN.

(option: 336hp,290hp)

Maximum torque: 1500Nm at 1100~1600   rpm

Bore: 126mm;   Stroke: 130mm;

Displacement: 9.726L;  Compression ratio: 17:1

Specific fuel consumption: 198g/kWh;

Engine oil filling quantity: 19L

Cooling system filling quantity   (long-term filling): 40L

Thermostat opening temperature: 71^oC

Rigid fan

Clutch

430mm diaphragm spring clutch,   hydraulic control with air assistance.WD615.47 engine standard is 430A model.

Transmission

SINOTRUK HW series. Model HW19710. 10   gears transmission, transmission with main and auxiliary transmission structure.   Main transmission with double counter shaft, auxiliary transmission with   planetary reduction, with PTO.

Ratio:10.73,7.89,5.91,4.38,3.29,2.45,1.82,1.35,1,   0.75

Front Axle

HR9, 9 ton, Steering with double   T-cross section. Disc Brake.

Option: drum brake.

Rear Axles

AC16, 16ton. Double Reduction(central   reduction+wheel reduction).Differential locks between wheels and axles

Ratio: 5.45 option:4.77

Option: HC16, ration4.42, 4.8,5.73

Chassis

Frame: U-profile parallel ladder type   with section of 300×80×8 mm,   all cold riveted cross members

Front suspension: Leaf spring   suspension,10pcs,with shock absorber, transverse stabilizer.

Rear suspension: Leaf spring   suspension,12pcs,disconnected type with transverse stabilizer

Spare wheel carrier: with one spare   wheel

Fuel tank: with 300 L fuel tank with locking fuel cap.

Steering

ZF8118(Left Hand Drive) , hydraulic   steering with power assistance.

Option: Right Hand Drive

Brakes

Service brake: dual circuit   compressed air brake

Parking brake :( emergency brake):   spring storage energy without air.

Auxiliary brake: Engine exhaust   braking. Standard engine EVB.

With ABS and optional auto clearance   adjusting arm.

Wheel & Types

Rims: 8.0-20, 10 hole-steel

Types 12R20

Option: 12.00-20 tube  12R22.5 etc.

Driver’s cab

Standard cab, with one berth. All   steel forward control, 55^o hydraulically tillable to the   front,2-arm windscreen wiper system with 3 speeds, laminate windscreen, with   casted-in radio aerial, hydraulically damped adjustable driver’s seat and   rigid adjustable co-driver’s seat, heating & ventilation system,   adjustable roof flap, with stereo radio/cassette recorder, sun visor, and   adjustable steering wheel, air horn, with 4-point support fully floating   suspension and shock absorber.

VDO instrument control module,   double-locking safety belt.

Option: Two Berth,

Electrics

Operating voltage:24V, negative   grounded;

Starter: 24V, 7.5KW

Alternator: 28V, 1500W;

Batteries: 2×12, 165Ah

Cigar-lighter, horn, headlamp, fog   light, reverse lamp

Dimensions in mm

Wheel base

Front wheel track

Rear wheel track

Front overhang

Rear overhang

Approach angle(^o)

Departure angle(^o)

Overall Dimension

Cargo body size

3625+1350

2022

1850

1500

1670

19

26

8145×2496×3386(mm)

5400×2300×1300 (mm)

(has different carriage size for option)

Weight in kg

Permissible loading capacity on   chassis

Dead weight

Gross vehicle weight

Front axle loading capacity

Rear axle loading capacity

12670

12200

25000

9000

16000×2

Performance

Maximum driving speed(km/h)

Maximum gradeablility (%)

Minimum ground clearance(mm)

Minimum turning circle(m)

Fuel consumption(L/100km)

75

50

314

16.3

28
