BOWNT BOS electric brush self-cleaning screen filter

● Electric drive, vertical installation, reliable and durable brush cleaning system.

● High efficiency, energy saving and low water consumption .

● Back washing cycle can be automatic activated by differential pressure and timing, without an interruption of filtration.

● Flange standard: ANSI B16.5/DIN2576/GB9119.

● Filtration grade optional for 50、100、200、300、500、800、 1500、2500、3500 micron and etc.

● Filter screen & shaft are made of SS 316L, optional for duplex 2205 and super duplex 2507.

● Filter housing is made of high quality carbon steel with anticorrosive treatment, optional for SS 316L, duplex 2205 and super duplex 2507.

● Max. working pressure: 145psi（1.0MPa） as standard, optional for 232psi（1.6MPa）and 362.5psi（2.5MPa）

● High anti-corrosive or explosion-proof requirements can be customized.

● All filters apply to hydraulic test before shipment to ensure a high quality.
