Automatic high speed computer NC corrugated cardboard cut off machine

Automatic high speed computer NC corrugated  cardboard cut off machine

Products Introduction:

1. It can store 200 units orders,replace the cutter specifications quickly and accurately,

    changing orders without stop,And enables networked computers to facilitate production

    management.

2. Knife shaft drive gears are precision forged steel induction hardening, backlash-free

     transmission, advanced keyless connection, high transmission accuracy.

3. Cutting machine adopts inlaid front steel blade knife spiral structure, serrated knife.

    scissors, shears, shear force, long blade life.

4. Around feed rollers are used  the sun gear platen way, smooth delivery, pressure evenly,

    easy to crush plate board or cause blockage.

5. This model is the braking energy storage (non-dynamic braking), so the energy consumption

    in the production process, the average electricity consumption is 1/3 of an ordinary NC

    cutting machine, saving more than 70% power to reach the goal of saving money .

6. Precision adjustable no gap gear to ensure precise blade engagement, running balance.

7. Using an independent oil pump and filter with two copper distribution in each gear position

   oil, lubrication and cooling.

8. Knife roller: fine quality forged steel material, the balanced, with good stability.

Technical parameters:

1.Max working width:1800mm

2.Operation direction:left or right(determined to the customer's factory)

3.Highest machinery speed:150m/min

4.Mechanical configuration:computer-control helical cross cutter

5.Minimum cutting length:500mm

6.Maximum cutting length:9999mm

7.Precision of cutting paper:uniform ±1mm,non-uniform±2mm
