Length(L)

2500~3000

  It could be produced by costomer's request

Total Width(W)

2500/2700/3000/3200

Height(H)

400

Conveyor belt

Plastic module conveyor belt, section distance25.4,material:POM

Conveyor bearing

High polymer polyethylene wear-resistant strip,composite board

Rack Material

t6 steel plate C fold edge, t10 steel plate,plastic spraying surface

Landing Leg Material

10#box iron ,plastic spraying surface

Bun foot

Steel foot cup,match M16 bolts,plus or minus 30 adjustable range,Zinc-plated surface

Driving mode

Head drive, middle drive (positive reverse)

Convey velocity

20m/min constant speed

Power of motor

2.2kw

Capacity

3000kg/set

Electronic control

PLC programming language automatic control
