carton die cutter machine corrugated carton machinerotary die cutting machinechain feeding
L/CT/TD/PWestern UnionPaypalMoney Gram
semi automatic rotary die cutting machine
Performance of the main mechanisms:
◆ chain feed
◆ the rubber roller adopt mechanical control the position move left and right.The movement distance is 40mm.
◆ The phase adopt electric 360°adjust, accord the error to input the adjust data,can be adjusted while the machine running or stop.
◆ The space adjustment between rubber roller and die roller adopt self-locking structure,with cylinder big scope quickly adjust,decrease the rubber wear,increase the rubber life.
◆ The space adjustment between the feed rollers adopt self-locking structure.
◆ The unique speed compensation device can make the rubber roller rolling running with the die roller,make the surface speed of the rubber cushion is completely controlled by the die roller, the shape of the carton sheet will absolutely equal to the die pattern.
◆ There is a rubber repair device with the machine,the rubber can be used after be repaired.
Technical parameters:
WYAZS NAME | UNIT | MODEL | ||
Max. paper coverage area | mm | 1400×2000 | 1400×2200 | 1400×2400 |
Effective die cutting area | mm | 1370×1800 | 1370×2000 | 1370×2200 |
Max. mechanical speed | pieces/min | 60 | 60 | 60 |
Power of main motor | kw | 5.5 | 5.5 | 7.5 |
