Product Category
Manufacturing & Processing Machinery > Apparel & Textile Machinery
Trademark
TYPICAL
I am a Buyer
OR
By clicking Sign in or logging in with Google or LinkedIn, I agree to the User Agreement and the Privacy Policy .
Business Type: Manufacturer
Main Products:Disposable mask automatic machineDisposable glove automatic machineKangaroo pocket folding & stitching machineAutomatic pattern sewing machineUltrasonic label piles and sealing machineNon woven bag automatic machineSolar street lightFabric automatic inspection machineIntelligent Virus checking HelmetBoxer automatic machine
ID:20111034967
Manufacturing & Processing Machinery Apparel & Textile Machinery
MOQ:2.00 Set(s)
Automatic sewing machine360° stitching sewing machine360° stitch linetemplate sewing machine
L/CT/T
| 型号Model | APNNE-TC162-139 |
| 机型结构Structure: | XY轴丝杆传动，无油干结构Screw rod X/Y axis, Dry structure, none oil. |
| 最大缝制面积Max. sewing area: | 1300 X 900mm |
| 最高缝制速度Max sewing speed | 3500 RPM |
| 旋梭Rotary hook: | 2.0 大梭 |
| 2.0 large rotary hook assort for thin and thick material as optional | |
| 针距Needle pitch: | 0.05mm ---12.7mm |
| 最大设计针数Max. stitches / design: | 100000 |
| 机针型号Needle model: | DPX5 8-18# |
| 压脚高度Presser foot height: | 最大Max15mm |
| 模板切换方式Template change style | 条形码智能切换 |
| Intelligent bar code scan | |
| 控制屏Control panel: | 10.4寸触摸屏 10.4’ touch panel |
| 程序（针路）输入Program input method: | USB falsh drive (32M-2GB) |
| 马达类型Main motor | 交流伺服AC servo motor |
| 电源规格Power supply: | 交流，单相220伏3安AC |
| Single phase 220V/3A | |
| 循环程序数MAX Cycle programs | 9 |
| 激光主要参数 Intelligent laser cloth cut equipment main parameters | Laser power:150w |
| Head size: 350*200*100（mm） | |
| Net Weight: 5.5KG | |
| Max cut area:1130*900mm | |
| Laser diameters: <0.4 | |
| Working temperature：-30---+65℃ | |
| Working humidity: 20%-85% Free from condensate | |
| Cooling way : Fan | |
| Vibration resitance:Amplitude 1mm frequancy 30HZ 2 hours | |
| 总功率Power capacity | 3450W |
| 气动规格Pneumatic specification: | 0.5-0.8mPa 2.5L/min |
| 机器尺寸Dimension: | 1850 x 950X 1100mm |
| 包装尺寸Packing size: | 2110X 1250 X 1605mm |
| 净重Net weight： | 650KG |
| 毛重Gross weight： | 800KG |
