High -definition.High speed ink printing electric slotter and die cutter with lead edge feeder

1050*2400Independent paper feeder 4 colors printer electrical slotter die-cutter

I. 主要技术参数 Main technical parameters

II. 具体配置 Detailed configuration

1.  送纸部：独立免压前缘，不损伤纸板； 电动延伸 (纸板最大延长900*2400）变频风机，变频电机。

Feeder part: Independent free pressure lead edge feeder, will not damage the cardboard flute and surface; automatic stretch(paperboard maximum extension is 900*2400) Frequency converter fan and motor.

2..送纸前缘部，前缘为免压 前缘送纸轮为6排轮，进纸轴为排轴（防止纸板横线部分打滑），配送除尘，气动拍齐，手动同时升降，自动分体，一键式调整机， 除胶轮外，前沿保三年。

Automatic lead edge feeder is free pressure type, feeding 6 wheels in rows, feeding shafts in rows can avoid the sheets sliding in feeding, except the rubber wheels, this feeder has 3 years warranty.

3.印刷部：为了换版方便，采用版辊双挂板

In order to change plate easily,use roller double hanging plate

4. 开槽部： 电动排刀, 开槽刀箱高及左右横移全部电动调整。

Slotter part: Electrical slotter knives adjustment in carton height and left right movement.

开槽组配置为：6轴电动排刀，5刀盘10根丝杠，电动横移，开槽部分电脑控制，一分钟换一次单。换单精度1毫米以内。

Slotter unit configuration: 6shafts electrical slotting knives movement, 5 slotting knives, 10pcs lead screw, electrical transverse movement, computerized control, order changing time 1minute, precision within 1mm.

5.网纹辊直径190mm,网线搭配目（可根据客户需求，如印满版用海力辊，效果更佳）。

Anilox roller diameter Ф190mm, mesh LPI as customer need (If print complete sheet with color, use Haili brand anilox roller, can reach better printing effect).

6.匀墨胶辊直径140mm。本机配2组刮刀 胶轴和网纹单相分离，印出效果更好

Ink distribution rubber roller diameter Ф140mm.,the machine equipped 2 sets scraper,rubber shaft and anilox  shaft single phase separation,better printing effect.

7.整机总功率：12千瓦

Complete machine total power: 25KW.

8.所有传动轴为钢管制成 每组带油孔，使机器润滑效果更好

All the transmission shafts are made of steel pipe,each part with oil hole,making better lubrication effects.

9.本机回墨斗为不锈钢材质，下回墨管直径40mm以防止堵塞

The returned ink tank is stainless steel material, down ink refill pipe diameter is 40mm to avoid blocking.

10.本机所有传动齿轮为40烙磨齿制成，且轴头连接为涨紧套连接（涨紧套浙江产）

All the driving gears on this machine is 40Cr material with precise grinding, and the shaft head is expansion sleeve connection (from Zhejiang).

11.本机所有调整杆都为冷拔电镀钢 电动调间隙 适合纸板范围1.5mm-4mm,本机网纹胶轴调压，送纸调压，版辊齿轮调压，圆模胶垫调压。

All the adjusting rods on this machine are cold-drawing electroplating steel.electric adjust gap，adopt cardboard range is 1.5-14mm,anilox roller  adjust pressure,paper feeder adjust pressure,roller gear adjust pressure,die-cutter rubber adjust pressure

12接触器：施耐德 ， 变频器：台湾三碁 ，PLC：台湾丰炜

圆压圆独立驱动器：德国科比 ，按钮选用正泰，继电器：日本欧姆龙

Contactor:Schneider ,    Transducer:SAVCH ,     PLC:VIGOR ,

Die-cutter independent driver:Germany KEB,   Button:CHINT,   Relay:OMRON

13.所使用轴承为：哈尔滨等知名品牌

Bearings brand: Ha’er bin brand.

14.润滑系统为：封闭式双油泵供油及回油，确保各机组油量平衡

Lubrication system: Closing type dual oil pump for oil supplying and returning, make sure the oil level is balancing and same in each machine unit.

15.主电机为7.5千瓦变频调速，风机变频调速，电量4.0千瓦

Main motor is 7.5kw frequency speed governor, fan frequency speed governor 4kw.

16.本机操作自动化为：采用气动供墨，墨辊与印版自动着墨与脱离，自动匀墨，电子眼计数器，电动相位并配有微电脑控制调整，各机组配有主机正反电动（调机速度快），各印刷组下横梁处配有脚踏开关，开槽固定组配有各组相位调整及控制主机速度，前缘组配有总锁紧功能，前后配有照明灯等人性化配置。

This machine is automation control: adopt pneumatic ink supplying, anilox roller and printing roller automatically touching with ink and separation, automatic ink distribution, electronic eye counting, electrical phase and equipped with micro computer control, each unit with host obverse and reverse electrical adjustment, more faster, equip with foot pedal under each unit, slotter unit with phase adjustment and can control complete machine speed, on feeder unit with general locking function, in front and back of machine has illumination for easy and convenient working, humanization.

17.气动抬板.气动锁紧，电动相位，电动分体，喷淋润滑 每组配带油位平衡器。

Pneumatic printing plate lifting up and down, pneumatic locking, electrical phase adjustment, electrical units separation and combination. Spray lubrication.each part equipped with oil level balancer.

18.电器面板选用不锈钢

Stainless steel material electrics operation panel.

19. 开槽切角选用碎屑自弹配置。

Slotter corner cutting adopt waste popup device.

20. 圆压圆免版开槽 独立驱动 驱动好处：印刷效果好，版辊和圆压圆自动左右蹿动

Die-cutter free slotting,independent driver,the advantage of driver :better printing effects,roller and die-cutter automatic movement left and right.
