600BPH 5 Gallon Mineral Water Bottle Sealing Packing Filling Machine price

600BPH 5 Gallon Mineral Water Bottle Cap Sealing Packing Filling Machine price

The whole process of washing, filling and capping is carried out in a closed channel to effectively prevent pollution and ensure the purity and purity of the produced water. Spraying station, including sterilizing water rinsing, circulating water rinsing, disposable pure water rinsing, draining station, etc., powerful flushing nozzle, thorough disinfection and rinsing; reasonable rinsing procedure, long time, washing 20-30 seconds, disinfection 10 -20 seconds, rinse with sterile water for 18-28 seconds. The filling is controlled by a time relay, and the plug-in seal is equal in pressure and accurate perfusion. The automatic feeding bottle is used to completely solve the "card bottle" phenomenon, and the separate cover and gland device are used, and the operation of each station is accurate, so that the washing and filling speed is efficient and smooth.

   Electric control box desktop structure, easy to operate and maintain automatic alarm function, fault self-diagnosis safe operation function, prevent card bottle stainless steel water pump imported AIRTEC cylinder, air valve and compressed air filter Germany Schneider electrical components.

   Adopt Japanese Panasonic programmable (PLC) controller, Schneider Electric components. It can be designed, produced, flexibly, easy to install and transport, and can adapt to various installation spaces. The standard output is 80 bottles, 150 bottles, 240 bottles, 300 bottles, 450 bottles, 600 bottles, 900 bottles, 1200 bottles, and so on.
