FLW36-12/24F(SOG) SF6 Insulation Load Break Switch

ID:20111135756

Category: Electrical & Power Energy Electrical Switches & Supplies

FOB Price:US$ 700.000 / Piece(s)

MOQ:500.00 Piece(s)

Product Keywords:

LOAD BREAK SWITCHVaccuum circuit breakerSF6 Load Break SwitchVacuum Load Break SwitchIndoor Vacuum Load BreakSF6 gas Switch

Payment Method:

L/CT/TD/PWestern UnionPaypalMoney Gram

Product Category

Electrical & Power Energy > Electrical Switches & Supplies

Trademark

SASUN

Product Package

Paper Carton

Specification

45 X 46 X 28

Place of Origin

CHINA

Port

YIWU

Summary

FLW36-12/24F(SOG) outdoor pole-mounted HV AC SF6 insulation load break switch type sectionalizer is suitable to the distribution network with rated voltage 12kV/24kV, rated current 400/630A, three-phase AC 50/60Hz to open and close the load current and short circuit current in the power system. It can automatically disconnect the distribution line segment in which the fault occurred. Equipped with the advanced electronic controller, the switch can be for manual operation, electric operation and remote operation. The electronic controller is installed in a stainless steel cabinet, so it can be used in all kinds of climatic conditions. The wire and wireless modems can be also installed in the cabinet to realize remote monitoring and control. Simple, convenient and quick pole mounting can lower the installation cost. The product conforms to the standards of IEC62271-103 & GB/T3804: 3.6kV~40.5kV AC high voltage load break switch and IEC60694 & GB/T11022: high voltage switch apparatus and control device.

Ambient conditions

1. Altitude: ≤3000m;

2. Ambient temperature: -40℃～+45℃；diurnal temperature rang ≤25℃;

3. Wind speed: ≤35m/s, equivalent to wind pressure of 700Pa;

4. Earthquake intensity: ≤grade 8;

5. Relative humidity: 100%;

6. Ice thickness: ≤10mm

7. Pollution degree: ≤Ⅳ(GB5582);

8. Applicable occasions: no fire and explosion danger, no chemical corrosion and no frequent severe vibration.
