Ⅰ. Product Description
Product name: Photoluminescent Ceramic Tile
Product model: HF-C-G500,HF-C-B500,HF-C-G500S,HF-C-B500S
Main Material: Inorganic materials such as clay, powdered quartz and feldspar, silica, strontium aluminate long afterglow luminescent powder.
Ⅱ. Characterize and Application Scopes :
The self-luminous ceramic tiles are made by pressing clay, powdered quartz and feldspar, silicon dioxide, long afterglow luminescent materials, etc. into the embryo body and firing. The product has all the characteristics and functions of ordinary floor tiles, and also has a self-luminous function.
It is an inorganic hard ceramic tile, is non-toxic and harmless, does not contain any radioactive elements, has long afterglow, high brightness, excellent weather resistance and wear resistance, and long service life. It can be widely used in the ground and wall surface of various places, playing a guiding role at night.
Ⅳ. Typical physical properties:
1. Regular Performance: meet GB/T4100-2015 《Ceramic Tile》Appendix G.
2. Dimension: 800 * 800MM
3. Thickness: 14 ~ 15MM
4. Weight: 30 kg / m2
5. Surface hardness: > 5 (Mohs hardness)
6. Temperature resistance: -40 ~ 180℃
7. Wear resistance: ≥3 grade / 1500 rpm
8. Radioactivity: Class A (GB 6566-2010 《Limits of Radionuclides in Building Materials》)
Luminosity Performance：（Excitation Condition：D65 Standard light source, illumination 1000LX，excitation for 10mins）
Name of Commodity | Model | Afterglow intensity (mcd/㎡) | Appearance | Glowing Color | |
10 min | 60min | ||||
PL Ceramic Tile (Glossy Surface) | HF-C-G500 | >438 | >26 |
|
Yellow-green |
HF-C-B500 | >550 | >90 |
|
Blue-green | |
PL Ceramic Tile (Anti-slip Surface) | HF-C-G500S | >438 | >26 |
|
Yellow-Green |
HF-C-B500S | >550 | >90 |
|
Blue-Green | |
Ⅴ. Performance
1. PL ceramic tile is made by firing self-luminous glaze and pressed base brick, possess excellent self-luminous performance and great weather resistance.
2. Possess excellent salt water and detergent resistance (it can be cleaned by detergent)
3. Possess excellent Hot temperature and Cold temperature resistance, could be used in the circumstance of -40 ~ 180℃. long life>30 years.
4. Possess good physical and mechanical performance.
Ⅵ. Notes & Notices for Use:
1. It is a fragile product, Pls pay attention to it during handling or cutting.
2. There might be slight color difference for different batch for same goods.
Ⅶ. Package&Storage & Transportation:
1. Package: sheet shape, wooden or pallet packed.
2. Transportation: prevent collision, squeeze, and handle gently during transportation.
3. Storage: stored in a dry, ventilated, cool warehouse with a storage temperature of -20 ~ 60 ℃.
