EPS CNC ROUTER ESCR-4
Effective working area: X=2000mm, Y=4000mm, Z=1000mm (size can be customized by customer need)
Max. feeding height: 1000mm
Working table: T-slot table
Driving way: Helical gear rack
Driver and Motor: Yaskawa servo motor X:1800W Y:1300W Z:1800W withbraker
Spindle Speed: 0-18000rpm
Max air move speed: 60000mm/min
Max working speed: 25000mm/min
Control system: SYCTEC11MB
Rotary: 700*3000mm with 2sets 850W Yaskawa servo motor
Inventer: 11kw Delta invente


Main characters
-Disc magazine fixed on the right beam, changing time need 10 seconds. Tool changer capacity is 8 pieces, convenient to complete complex processing tasks of multiple head
-Industrial control system, continuous carving during power failure and break point and speed control with the easy one button operation, high efficient ,it can compatible with Type3,Artcam,Alphacam,ARTCUT,JD Paint etc. CAM software from home and abroad
-Adopt imported new anti-environment type servo motor and driver, with fast speed, high precision and shock resistance. Besides the protection class of servomotor is IP65.It can be used in Harsh environment safely
-Other models are available
