PU Layflat hoseLayflat hoseTPU Layflat hosepolyurethane hoseASOEwater hose
L/CT/TD/PWestern UnionPaypalMoney GramOthers
Mileflex is one type of super heavy-duty through-the-weave polyurethane (PU) covered hose. Mileflex hoses shall be made from 100% high tenacity synthetic yarn circular woven and completely, totally embedded in the PU compound, excellent protected against mechanical damage, forming a single homogenous construction without the use of any glues or adhesives of any type.
Mileflex? PU Layflat Hoses | |||||||||
ID | Wall Thickness | Weight | Working Pressure | Bursting Pressure | |||||
Inch | mm | Inch | mm | lbs/ft | kg/m | PSI | bar | PSI | bar |
1 1/2 | 38+1.5 | 0.09 | 2.2 | 0.2 | 0.3 | 300 | 21 | 900 | 63 |
2 | 51+1.5 | 0.11 | 2.7 | 0.34 | 0.5 | 300 | 21 | 900 | 63 |
2 1/2 | 64+1.5 | 0.12 | 2.9 | 0.44 | 0.65 | 300 | 21 | 900 | 63 |
3 | 76+2.0 | 0.12 | 3 | 0.5 | 0.75 | 250 | 17 | 750 | 51 |
4 | 103+2.0 | 0.13 | 3.2 | 0.78 | 1.16 | 250 | 17 | 750 | 51 |
6 | 154+2.5 | 0.17 | 4.2 | 1.56 | 2.33 | 200 | 14 | 600 | 42 |
8 | 204+3.0 | 0.175 | 4.5 | 2.3 | 3.43 | 215 | 15 | 645 | 45 |
10 | 254+3.0 | 0.18 | 4.6 | 3.08 | 4.59 | 200 | 14 | 600 | 42 |
12 | 305+3.0 | 0.185 | 4.7 | 3.36 | 5.01 | 150 | 10 | 450 | 30 |
Application: Suitable for use and recommended for frac water transferring, dewatering in mining and water transfer in harsh environment.
Inner tube and cover: Smooth PU cover and tube.
Reinforcement: Circular woven polyester jacket
Operating Temperature Range: From -60° F to 176°F (-50° C to 80° C)
Standard Color: Black, other colors available per request
Standard Length: 50ft, 100ft, 300ft/91.5m, 330ft/100m, 660ft/200m; other lengths available per request;
Couplings: LDHC V couplings, LDHC FM Couplings, LDHC S (Storz) Couplings, etc.
Warranty: 5 years guarantee
