Galvanized Wire for PVC wire hose

The galvanized wire is very soft and Flexible.  it is widely used in PVC wire hose,PVC intensifier tube,PVC Steel Wire Hose manufacturer.

Galvanized iron wire, GI Wire, GI Binding Wire, Electro galvanized wire

1.Materials:(a). Mild steel wire (b). bullet wire (c). high-carbon steel wire
2.Wire gauge size: hot-dipped galvanized wire: 8# to 36#(wire diameter ranging from 3.8mm to 0.19mm)
electro galvanized wire: 8# to 38# (wire diameter ranging from 3.8mm to 0.15mm)
3.Processing: First draw (the material of wire rod to the right wire diameter0---Wire Annealing---Rust Removing--- Acid Washing--- Boiling--- Drying--- Zinc Feeding--- Wire Coiling.
4.Zinc coating:   8-15g/mm2 electro galvanized, 30-70g/mm2 hot dip galvanized, 100-500g/mm2 heavy duty galvanized zinc coat.
5.Elongation: 10-15% for low carbon steel wire
6.Tensile strength: 350-550n/mm2 soft,550-950n/mm2 hard drawn, 1000-2600n/mm2 high tensile strength.

Application Of Galvanized Wire/ Iron Wire
1) binding wire or building wire for construction
2) weaving wire mesh
3) making express way fence
4) handcraft
5)PVC wire hose;HYDRAULIC HOSE,PVC Wire Reinforced Hose

More Information Galvanized Wire/Iron Wire
Electro Galvanized Iron Wire/Galvanized Wire Technical Information: Processing with low carbon steel wire, through drawing and electro galvanizing.

Standard wire gauge for electro galvanized iron wire: 8# to 38# (wire diameter ranging from 3.8mm to 0.15mm) Electro Galvanized Iron Wire  uses:  Electro Galvanized Iron Wire is used in weaving of wire mesh, fencing for expressway and construction.

Hot-Dip Electro Galvanized Iron Wire Technical Information: Material: super carbon steel Processing by drawing, hot-dip zinc coating.

Hot-dip galvanized iron wire standard wire gauge: 8# to 36#(wire diameter ranging from 3.8mm to 0.19mm) Hot-dip galvanized wire property: Thick zinc-coating layer of hot-dipped galvanized iron wire offers super corrosion resistance with firm coating layer. Custom size available.
