NOTE:

FOB (Zhuhai,Shenzhen, HK) or CIF prices are available based on your specific needs.

Technical specifications of the product：

Rated power：350W+350W（8Ω）

Frequency response（1dB）：（MUSIC MIC）20Hz~20KHz

Input voltage : 100-240V,50/60Hz

(AC/DC Adapter in line with international standards:

Output:safety voltage DC

Safety certificates such as CE, UL, etc. & plugs suitable to different nations are available)

Frequency response：20Hz-20KHz±0.5dB

Total harmonic distortion：＜0.5%@1KHz 8Ω 1/3 Rated Power

Input voltage ：AC 220V~50Hz (AC input power cords suitable to different nations are available)

Noise-signal ratio（A weighted）：≥92dB

Size：88×482×390 (unit: mm)

Features of the product：

1. Using 24 bit data bus and 32 bit advanced technology.

2. Double-reverberation microphone humanized automatic frequency shift technology plus professional feedback suppression anti-scream technology, effectively suppress howling.

3. Functions of setting the volume of music, microphone, turning-on and locking max volume are easy to use.

4. Full-code format output of bluetooth, USB/SD built-in front panel can provide users with more flexible options .

5. Adopting SMT patch production process ensures the product performance to be extremely stable.

6. Microphone output, main output have functions of voltage limit, output gain adjustable, time delay and adjustment .

7. Allow up to five microphone input (front panel three and rear two), volume of each microphone can be controlled separately, convenient for users.

8. Three audio input and one monitoring listening output.

9. LCD display microphone volume, music volume and input status. Get important parameters just at a glance.

10. Output terminals：NL4MP×2+professional plum type wiring posts ×2

11. Reliable over-voltage, overload, temperature control protection circuit can protect the product from possible related damages thus caused.

12. The optical fiber coaxial digital signal input port ensures 100% lossless signal input.

13. The product has the advantages of high sensitivity, good sound quality and durable to use.

14. Wide audio response frequency range of the product covers the frequency range of sound waves that can be heard by human ears. Whether it is deep bass, melodious mediant, or loud and clear treble, all voice can be perfectly transmitted and reproduced to ensure the Hi-Fi sound effect.

15. Advanced CPU and exclusive designed software are used to make the whole system run accurately, efficiently and professionally.

16. All the receiver panels are carefully designed, reasonably arranged and easy to operate.

17. Years of experience, professional design, quality materials and components, plus meticulous manufacturing process, create together the excellent product w/ high quality and pretty appearance.
