Applications:

As single core for internal wiring of devices as well as protected laying within and on luminaires. Laying within pipes on wall and in wall permitted for signal facilities.

Conductor:

Copper conductor, bare single wire according to VDE 0295 cl. 1

Insulation:

PVC TI1 according to HD 21.1 S3

Core identification:

 According to VDE 0293

Nominal voltage Uo/U

300 / 500 volts

Test voltage:

2000v

Temperature range:

Fixed installation: -40°C to 70°C

Flexing: 5°C to 70°C

Min bending radius:

4 x cable diameter

Standards:

This product corresponds to the directive 2006/95/EGCE (low voltage directive). BS6004 Electric cables. PVC insulated, non-armoured cables for voltages up to and including 450/750V, for electric power, lighting and internal wiring
