Equipment performance parameters:

1. Equipment production capacity: Design volume: 265L, use volume: 200L;

2. Mixing barrel specifications: inner diameter ￠ 750mm, depth 600mm; using SUS304 material, finish turning, fine grinding, double sandwich stainless steel water bath type.

3. Revolution:

3.1 Two sets of twist-type mixing paddles, SUS304 material, precision processing;

3.2 revolution speed: 0~31 rev / min, stirring paddle speed: 0-65 rev / min, frequency control.

3.3 Power: 15KW

3.4 Mixing paddle assembly accuracy:

3.4.1 The gap between the stirring and the barrel wall is 3-5mm, and the gap between the stirring paddle and the stirring paddle is 6-10 mm;

3.4.2 The gap between the stirring paddle and the bottom of the container is 4mm±1mm.

4. Self-rotation (2 sets)

4.1 Two sets of dispersing shafts, each with 2 φ155mm dispersing discs, SUS304 material;

4.2 Rotation speed: 0~3000 rev / min, frequency control.

4.3 Power: 22KW

5. The vacuum degree can reach -0.098Mpa, and the user can prepare the vacuum equipment;

6. Temperature control range: 20~90°C, temperature difference ±1°C, temperature measurement point is located in the inner wall of the barrel and is in direct contact with the material.

7. Material:

7.1 The material in contact with the material part is SUS304 stainless steel;

7.2 The main machine is made of Q235 steel.

8. Lifting stroke: 700mm, lifting method: hydraulic cylinder lifting mixing bucket.

9. Control method: manual control.

Guide roller adopts alumina tube, surface roughness Ra1.6um; super hard oxidation

The surface is smooth and anodized, the coating is ≥0.15mm, the surface color is brown, the surface roughness of the guide roller is Ra: 0.4; the cylindricalness of the guide roller is ≤ 0.03mm, and the full runout of the guide roller is ≤ 0.05mm

The winding tension can be quantified by (tension) × (number of strips), and the tension base can be automatically adjusted according to different slitting widths.Set tension coefficient by yourself, continuously ensure constant tension and stable tension, continuous cutting will not cause belt break

Transfer the loading of the car to the unwinding shaft, manually start the cutter, and manually send the pole pieces into the knife holder for pre-slitting through the tension mechanism. On the slip shaft, fix the pole piece that is passed to the differential shaft to the winding sleeve with tape.
