Business Type: Manufacturer
Main Products:film blowing machineplastic film blown machineABA plastic film blown machinefilm extruder machineplastic film extrusionABC film blowing machinebiodegradable plastic film blowing machineTable cover film blowing machine
ID:20120446606
Manufacturing & Processing Machinery Plastic,Rubber Machinery & Moulds
MOQ:1.00 Piece(s)
plastic film blowing machinefilm extruder machineblown film extrusion machineextrusion film
L/CT/T
ML-ABA/45-45/900 | ML-ABA/50-50/1200 | ML-ABA/55-55/1400 | ML-ABA/65-65/1600 | ML-ABA/75-75/2000 | ||
Film width | T-shirt bag | 200-620mm | 250-600mm | 300-1000mm | 500-1200mm | 1200-1600mm |
Flat bag | 200-800mm | 250-800mm | 500-1100mm | 500-1300mm | 1200-1800mm | |
Film thickness | 0.006-0.15mm | 0.006-0.15mm | 0.006-0.15mm | 0.006-0.15mm | 0.006-0.15mm | |
max output | 80-90kg/h | 90- 125kg/h | 100- 150kg/h | 120- 175kg/h | 120-200kg/h | |
According to different width,thickness of film, die size and raw material characteristics to change | ||||||
Raw material | HDPE/LDPE/LLDPE | HDPE/LDPE/LLDPE | HDPE/LDPE/LLDPE | HDPE/LDPE/LLDPE | HDPE/LDPE/LLDPE | |
Diameter of screw | Φ45/45,30/1 | Φ50/50,30/1 | Φ55/55,30/1 | Φ65/65,30/1 | Φ75/75,30/1 | |
SACM 645 ,bimetallic ，five years guarantee | ||||||
Main motor | 15kw ,15kw | 18.5kw ,18.5kw | 30kw ,30kw | 37kw,37kw | 37kw,37kw | |
100% Original three-phase variable frequency motor Equipped with inverter control | ||||||
Take up roller(mm) | 700/900mm | 1200mm | 1400mm | 1600mm | 1800mm | |
2800kg | 3200kg | 3800kg | 4200kg | 4800kg | ||
Machine size | 6.5*2.7*5 | 6.5*3*5.8 | 6.5*3.8*6.2 | 6.8*4*6.8 | 6.8*4*7.2 | |
Note:the above specifications,dimensions&design characteristics are subject to change without notice
Optional device:
Automatic Hopper Loader
Film Surface Treater
Rotary Die
Oscillating Take Up Unit
Two Stations Surface Winder
Chiller
Heat Slitting Device
Gravimetric Dosing Unit
IBC(Internal Bubble Cooling Computer Control System)
EPC(Edge Position Control)
Electronic Tension Control
Manual mechanics screen changer
Edge material recycling machine
