Color liquid crystal display electrocardiograph six-channel portable hospital equipment

Features

l 6 channel ECG machine with automatic interpretation

l Manual/Auto working Modes

l Simultaneous 12 leads acquisition and 6-ch recording with high resolution thermal printer.

l 4.3 inch Color TFT LCD display ECG wave and friendly menu setting.

l Support touch panel and keypad input ways

l Support SD card storage.

l 120 seconds ECG wave freeze and replay function.

l Lead-off detection and alert

l Digital filtering, resisting baseline drift, AC and EMG interference

l Built in USB/RS232 interface(ECGNET software optional)

l Built in rechargeable Li-ion battery support less than 3 hours continuously work.

l AC power supply at 90-240V@50/60Hz

Technical Specification

●  Lead: standard 12 leads

●  Lead acquisition: 16 bit /24bit 1000Hz（synchronously 12 leads）

●  Work modes: MANUAL、AUTO modes

●  Filter:

 AC Flter : 50Hz / 60Hz

 EMG Filter : 35Hz / 45Hz

 Anti-Drift Filter : 0.15Hz (Adaptive)

●  CMMR: ≥100dB (with AC filter)

●  Input circuit: floating; protection circuit against defibrillator effect

●  Input Impedance: ≥50MΩ

●  Input circuit current: ≤0.05μA

●  Input dynamic range: ±5mVpp

●  Patient current leakage: ＜10μA

●  Calibrating voltage: 1mV±2％

●  Voltage tolerance:±600mV

●  Time constant: ≥3.2s

●  Frequency response: 0.05～150Hz(-3db)

●  Noise level: ＜15μVp-p

●  Sensitivity valve: ≤20μV

●  Sensitivity: 2.5, 5,10,20mm/mV

●  Inter-channel Interference: ≤0.5mm

●  Printer：110mm thermal printer ，adjusted print speed: 5, 10,12.5, 25, 50mm/s（±3％）

l 100 patient information storage.

●  Display:

 UN-8006A: 4.3 inch TFT LCD with touch panel.
