Digital 3-channel ECG machine portable medical ecg

Quick Details
Place of Origin:HUbei,China                           Brand Name:Wuhan Union Medical

Model Number: UN8003                                 Power Source:Electic

Warranty:1 years,18 months                          After-sale Service:Return and Replacement

After-sale Service:Return and Replacement   Power Supply Mode:Plug-in

Material:plastic                                     Shelf Life:3 years

Quality Certification:ce                        Instrument classification:Class II

Safety standard:GB15979-2002           Type:Blood Pressure Monitor

Product name:ECG Machine                Color:white

Weight:3.0kg                                        Name:Digital 3-channel ECG machine portable medical ecg                           Net weight:1.5 kg (with battery)

Lead:standard 12 leads                        Work modes:MANUAL,AUTO modes

Description:
UN-8003 is a portable and high quality 3-channel ECG, which offer not only normal thermal printing but also external printing solution. It can used in hosipital. Clinic and emergencyies.

Technical Specification

●  Lead: standard 12 leads

●  Lead acquisition: 16bit/24bit 1000Hz（synchronously 12 leads）

●  Work modes: MANUAL、AUTO modes

Filter:

●  AC Flter : 50Hz / 60Hz   EMG Filter : 35Hz / 45Hz   Anti-Drift Filter : 0.15Hz (Adaptive)

●  CMMR: ≥100dB (with AC filter)

●  Input circuit: floating; protection circuit against defibrillator effect

●  Input Impedance: ≥50MΩ

●  Input circuit current: ≤0.05μA

●  Input dynamic range: ±5mVpp

●  Patient current leakage: ＜10μA

●  Calibrating voltage: 1mV±2％

●  Voltage tolerance:±600mV

●  Time constant: ≥3.2s

●  Frequency response: 0.05～150Hz(-3db)

●  Noise level: ＜15μVp-p

●  Sensitivity: 2.5, 5,10,20mm/mV

●  Inter-channel Interference: ≤0.5mm

Display:

UN-8003: 4.3 inch TFT LCD with touch panel.

Company:

We,Wuhan Union Medical Technology CO.,Ltd,is a R&D company in patient monitoring solutions,which started in 2009 with leading engineers in China,and established in 2013.Union Medical is committed to the techniques and products of monitoring, diagnosing, supporting and treating the biological information; serving the society; improving human health. Union Medical focused on the development of patient monitoring solutions with engineers who have experience in this area for more than 15 years.Our main solutions are about the non-invasive and invasive solutions for patients vital sign parameters,technologies as: algorithm for ECG diagnosis,pulse oxygen monitoring,respiration gas monitor, respiratory monitoring,electronic sphygmomanometer etc.Vital sign parameter modules:ECG module,SPO2 Module,NIBP Module,IBP Module,Six-parameter Module,Multigas Module etc. We also produce our own final monitoring equipments,like ECG machines,patient monitors,vital sign monitors,pulse oximeters,ETCO2 monitors/Capnometer/Capnograph,Anesthesia Multigas monitors etc. All our solutions/products are for improving the industry of human health.
