Anti-static steel raised access floor tile with PVC finish

ID:21042950401

Category: Construction & Decoration Flooring

FOB Price:US$ 10.000 / Piece(s)

MOQ:1.00 Piece(s)

Product Keywords:

Anti-Static Flooringraised flooraccess floorelevated floorPVC finish raised floordata center raised floorcomputer room raised flooradjustable height raised floorhigh loading raised floorfalse floor tile

Payment Method:

L/CT/T

Product Category

Construction & Decoration > Flooring

Trademark

Xiangli

Product Package

pallet

Specification

600*600*35mm

Place of Origin

China

Port

Shanghai

Anti-static PVC finish steel raised access floor system for data center,computer room

Product Description

xiangli2

Description

1.With wildly brand top tiles,such as HPL,PVC,ceramic marble,granite,wood ,laminate floor ,anti- static ,fireproof ,wear resistant.

2.High dimensional precision,new patent”cross strengthening rib ” structure, strong loadability and shockproof

3. Adjustable height for pedestal , assembly agility, large wire, good exchangeability

4. stringer connect ,flat pedestal ,High loading capacity ,steady for the system

5. etc caused by cement,brick,wood floor embedded the wires in advanced

6. High recycled, convenient removing, saving cost, long performance life

The newest “ cross strengthening rib ” structural design on the back of this raised access floor in all steel. This strengthening rib forms cross in the frame of floor. Soleplate is punched forming at one time, building raised floor with panel filled support main body. “ XiangLi ” Company succeed in researching this design and applying patent in 2006. This floor is applied to computer room or equipment room which requires higher load bearing in particular. “ XiangLi ”brand be printed on the side of the floor for customer identification. Compare with uniform product, this utility model structural design is more advanced in both appearance and loading. Ingenuity but a little cost. Especially in the loading, there is more 20% loading than uniformity for each floor. Ours supply consumer with far better quality guarantee, then we recommend strongly this structural floor.

Patent design

Forgery prevention identification

Compare with other normal floor and “ XiangLi ”patent floor

Item	Normal floor	“XiangLi ”patent floor
Requirement on steel	Normal flexible steel	Shanghai bao steel hard cold rolled steel
Appearance and dimension	Normal structure, reshape one time or even no reshape, dimensional variation	Patent “ cross strengthening rib ” structure, elegant appearance, many times reshape, high dimensional precision
Concentrated load	At or below national standards	Owe to patent “ cross strengthening rib ” structure, loading than national standards
Antisepsis, antirust, wearproof	Normal domestic paint, easy rust, short time for wear	Imported paint, difficult rust, high wearing
Cement infilled	Normal cement and contain many cinders, underfill	GB foaming cement, free of cinder, filled with unique strong oscillatory type, guarantee cement full and uniform
Glue and regula	Normal glue, un-special technology on regual, easy drop	Imported glue, rolling paste tile, regula pasted with 502 strong glue, difficult drop
Mechanical property	Singel spotweld, few bonding point, small bonding force between upper platen and lower platen	Advanced multipoint spot welder, uniform bonding point strong structural capacity between upper platen and lower platen
Service life	1-5 Years	10-15 Years
Brand identification	No special mark, brand confusion, taking substandard products as fine pruducts	Priting Chinese or English “ Xiang Li ” on steel body for customer identification

Application

Wide range All manner of computer room, network service room monitor control center, electronic workshop, clean room, dustlessness chamber etc, and occasions which require on antistatic and air conditioning

And 5 class office Security Union Plaza ,Futures Trading Building , and the place demand cabling and wiring .
