Anti-Static Flooringraised flooraccess floorfalse floorelevated floorwood core raised floorHPL finish raised floorAdjustable heightdata center usecommunication room use
L/CT/T
HPL coated wood core raised access floor which can prevent static electricity used in computer room or data center
1.High density particle board,PVC/ABS edge trim, sound proof
2.High dimensional precision, strong loading ability and shockproof.
3.Adjustable height for pedestal , assembly agility, large wire, good exchangeability.
4.Outlet mating . Elegant appearance for paving wildly brand top tiles.
5.light weight ,high loading capacity ,excellent raised flooring in 21th
6.light weight ,convenient removing, saving
structure
1.panel- 30/38mm thickness particle board ,PVC/ABS corvered four edges,steel/aluminium on the bottom plate ,wildly brand top tiles is HPL.
2.Accessories -die casting steel structure pedestal plastic gasket on top ,height could be 70mm ---1500mm , with or without square tube stringer steady connect the system
Application
Wide range of the application , all kinds of computerroom, network service engine room, control room, montoring cabin, top grade office
Type& Technology parameter
Type | International | Size(mm) | Fire Performance | Concentrated load | Impact load (N) | Ultimated load (N) | Uniform Load (N/m2) | Rolling load(N) | |||
LB | N | KG | 10 times | 100000 times | |||||||
XL-2001 | FS440 | 600x600x32 | A | ≥440 | ≥1960 | ≥200 | ≥295 | ≥5880 | ≥9272 | 1958 | 1566 |
XL-2002 | FS662 | 600x600x40 | A | ≥662 | ≥2950 | ≥301 | ≥445 | ≥8850 | ≥1250 | 2946 | 2356 |
XL-2003 | FS800 | 600x600x40 | A | ≥800 | ≥3350 | ≥363 | ≥536 | ≥11250 | ≥16100 | 3560 | 2670 |
