Features Of HK60Z-JS Multi-turn Electric Actuated Globe Valve:
● Features of multi-turn electric globe valve including easy to wire and control. Well equipped with gate valve and globe valve.
● Offering the best linear solution for various applications.
● Remote control and manual control are available.
● Widely used for power plants, paper and pulp, oil and gas and so on.
● Available in Profibus Fieldbus, Modbus Fieldbus, Hart Fieldbus, FF Fieldbus and Device Net Fieldbus
Technical Parameters Of Globe Valve:
| Medium | Air, water, steam, oil, liquid, etc | End Connection | Flange |
| Port size range | 1/2 inches to 16 inches | Design Standard | ANSI / JIS / DIN / GB |
| Body Material | WCB, CF8, CF8M are accepted | Working Pressure | 10 / 16 / 20 / 64 bar |
| Temperature Of Media | -30℃ to 400℃ | Function | Start, stop or regulation |
Technical Parameters Of Electric Globe Valve Actuator:
| Working Voltage | Three-phase: 380V AC. Range: 380VAC ~ 420VAC Single-phase: 220V AC. Range: 200VAC ~ 240VAC |
| Ambient Temperature | -20℃ to 70℃ |
| Working Temperature | ≤90%RH |
| Analog Signal Switch | DC4~20mA |
| Input Signal | Built-in 24V DC power supply, Public terminal FOR 24V + |
