Flemish Eye Sleeves

ID:21061156266

Category: Tools,Hardware & Instruments Fasteners

FOB Price:US$ 0.230 / Piece(s)

MOQ:1000.00 Piece(s)

Product Keywords:

Flemish Eye SleeveCarbon Steel SleeveWire Rope SleeveLifting SlingS505

Payment Method:

L/CT/TD/PWestern Union

Product Category

Tools,Hardware & Instruments > Fasteners

Trademark

Klifting

Product Package

Carton

Specification

Place of Origin

China

Port

Qingdao

We are the leading manufacturer of Flemish Eye swaging sleeves in China. All our Flemish Eye sleeves have corrosion protection and are made according to the highest quality standards. Surface treatment could be black oxidized or galvanized. Sleeves are stamped for traceability with code, size, and batch number.

All our Flemish Eye swaging sleeves are tested for better swageability. Testing includes hardness test, chemical analysis, microstructure analysis and closed ?attening test according to EN 13411-3:2004 standard.

The Flemish Eye sleeves satisfy the European standards, EN 13411-3, for mechanical splicing.

Sleeves are recommended for use with 6x19, or 6x37, IPS or XIP (EIP), XXIP (EEIP), RRL, FC or IWRC wire rope.

Not applicable on rotation resistant wire ropes. When properly applied, the terminations have an e?ciency rating of more than 90% according to EN 13411-3, based on the catalogue strength of wire rope.

NOTE! Before using our Flemish Eye sleeves with any other type lay, construction or grade of wire rope, it is recommended that the termination to be destructive tested to prove the adequacy of the assembly to be manufactured.

Flemish eye sleeves
Part No.	Ferrule Code	The size of rope(inch)	Size(inch)					Size after swage(inch)	Weight kg/100pcs
Part No.	Ferrule Code	The size of rope(inch)	A	B	D	E	C	Size after swage(inch)	Weight kg/100pcs
KFS11060	6	1/4''	1	0.66	0.31	0.28	0.47	0.57	2.27
KFS11080	8	5/16''	1.5	0.91	0.38	0.44	0.62	0.75	6.36
KFS11100	10	3/8''	1.5	0.91	0.47	0.39	0.66	0.75	6.36
KFS11110	11	7/16''	2	1.22	0.53	0.65	0.85	1.01	15
KFS11130	13	1/2''	2	1.22	0.63	0.56	0.91	1.01	13
KFS11140	14	9/16''	2.75	1.47	0.7	0.63	1.03	1.24	29
KFS11160	16	5/8''	2.75	1.47	0.75	0.63	1.09	1.24	26
KFS11190	19	3/4''	3.19	1.72	0.91	0.84	1.28	1.46	40
KFS11220	22	7/8''	3.56	2.03	1.03	1	1.53	1.68	60
KFS11260	26	1''	4	2.28	1.16	1.13	1.72	1.93	89
KFS11280	28	1-1/8''	4.8	2.5	1.28	1.25	1.94	2.13	118
KFS11320	32	1-1/4''	5.19	2.78	1.44	1.41	2.16	2.32	161
KFS11350	35	1-3/8''	5.81	3	1.56	1.56	2.38	2.52	192
KFS11380	38	1-1/2''	6.25	3.25	1.69	1.69	2.63	2.71	227
KFS11450	45	1-3/4''	7.25	3.84	1.94	1.97	3.13	3.1	366
KFS11500	50	2''	8.5	4.38	2.25	2.25	3.63	3.56	514
KFS11570	57	2-1/4''	9.56	5.03	2.5	2.53	4.03	4.12	879
KFS11640	64	2-1/2''	10.5	5.5	2.75	2.81	4.5	4.5	1068
KFS11700	70	2-3/4''	11.5	5.75	3	3.09	4.75	4.7	1271
KFS11760	76	3''	12	6	3.25	3.38	5	4.96	1335
KFS11820	82	3-1/4''	13	6.5	3.86	3.54	5.43	5.37	1650
KFS11890	89	3-1/2''	14	7	3.88	3.94	5.84	5.77	2106
KFS11950	95	3-3/4''	15	7.5	4.06	4.25	6.31	6.23	2497
KFS11100	100	4''	16	8.13	4.38	4.5	6.81	6.69	3087
KFS11115	115	4-1/2''	18	9.13	4.88	5.06	7.66	7.45	4540
KFS11130	130	5''	20	10.52	5.5	5.63	8.73	8.28	6600
KFS11150	150	6''	24	12.54	6.5	6.75	10.2	9.93	12300
