Wire Rope ThimblesHeavy Duty ThimblesEN13411-1BS464 G414G411DIN3091
L/CT/TD/PWestern Union
Available in hot dip galvanized or stainless steel(Type 304 or 316).
Stainless steel recommended for more corrosive environments where greater protection is required.
Greater protection againest wear and deformation of the wire rope eye.
Longer service life.
NO. | Size (inch) | Dimensions(inch) | WT/PC （kg） | |||||||
A | B | C | D | E | F | G | H | |||
KG414006 | 1/4 | 2.19 | 1.62 | 1.50 | 0.88 | 0.41 | 0.28 | 0.06 | 0.25 | 0.012 |
KG414008 | 5/16 | 2.50 | 1.88 | 1.81 | 1.06 | 0.50 | 0.34 | 0.08 | 0.30 | 0.05 |
KG414010 | 3/8 | 2.88 | 2.12 | 2.12 | 1.12 | 0.63 | 0.41 | 0.11 | 0.39 | 0.1 |
KG414011 | 7/16 | 3.25 | 2.38 | 2.38 | 1.25 | 0.72 | 0.47 | 0.12 | 0.45 | 0.136 |
KG414013 | 1/2-9/16 | 3.62 | 2.75 | 2.75 | 1.50 | 0.89 | 0.59 | 0.15 | 0.48 | 0.22 |
KG414016 | 5/8 | 4.25 | 3.25 | 3.12 | 1.75 | 1.00 | 0.66 | 0.16 | 0.53 | 0.32 |
KG414019 | 3/4 | 5.00 | 3.75 | 3.81 | 2.00 | 1.22 | 0.78 | 0.22 | 0.69 | 0.6 |
KG414022 | 7/8 | 5.50 | 4.25 | 4.25 | 2.25 | 1.38 | 0.94 | 0.22 | 0.78 | 0.86 |
KG414025 | 1 | 6.12 | 4.50 | 4.75 | 2.50 | 1.56 | 1.06 | 0.25 | 0.88 | 1.06 |
KG414032 | 1-1/8 to 1-1/4 | 7.00 | 5.12 | 5.88 | 2.88 | 1.88 | 1.31 | 0.25 | 1.25 | 1.54 |
KG414035 | 1-1/4 to 1-3/8 | 9.08 | 6.50 | 6.81 | 3.50 | 2.25 | 1.44 | 0.37 | 1.29 | 3.71 |
KG414038 | 1-3/8 to 1-1/2 | 9.00 | 6.25 | 7.12 | 3.50 | 2.62 | 1.56 | 0.50 | 1.31 | 4.2 |
KG414041 | 1-5/8 | 11.25 | 8.00 | 8.12 | 4.00 | 3.00. | 1.72 | 0.50 | 1.38 | 6.25 |
KG414045 | 1-3/4 | 12.19 | 9.00 | 8.50 | 4.50 | 3.06 | 1.84 | 0.50 | 1.50 | 7.1 |
KG414051 | 1-7/8 to 2 | 15.12 | 12.00 | 10.38 | 6.00 | 3.38 | 2.09 | 0.50 | 1.69 | 10.44 |
KG414057 | 2-1/4 | 17.5 | 14.00 | 11.88 | 7.00 | 3.88 | 2.38 | 0.62 | 1.82 | 18.44 |
