● The machine body is welded from high-manganese steel plate, and has the advantages of anti-tensile, anti-vibration, durable and not easily deformed. It is configured with ultrahigh-pressure pump system, ensuring plenty of power to easily complete the experiment.
● The high-precision load cell, calibrated by a national-level metrology institute, has measurement accuracy better than 1%.
● The tension test is controlled by computer, with simple operation interface and complete functions. The test can be completed by simply operating the mouse for selection. It can display data and corresponded curves in real time.
● The computer will directly finish data acquisition and analysis after the pull test, and then print test report and line chart.
● The equipment can complete various forms test, such as static tension test, breaking tension test, displacement test, and fatigue test, etc.
● The machine is applicable to tensile test for various riggings, such as steel wire rope, steel wire rope, hoisting belt, strong ring, and shackle, etc. We can also provide tensile test solutions for profiled parts according to customer needs.
● We can customize according to your needs.
| SPECIFICATION OF TEST BED | ||||||||
| NO. | ITERM | K-LD300KN | K-LD600KN | K-LD1000KN | K-LD2000KN | K-LD3000KN | K-LD4000KN | |
| A | Effective Length | 3000 | 4000 | 12000 | 12000 | 8000 | 8000 | |
| B | Maximum Length | 6500 | 8000 | 17000 | 18000 | 15000 | 16000 | |
| C | Maximum Width | 1000 | 1250 | 1400 | 1800 | 1900 | 2200 | |
| D | Inner Width | 600 | 750 | 800 | 1100 | 1100 | 1200 | |
| E | Machine Height | 300 | 380 | 420 | 550 | 650 | 700 | |
| F | Maximum Height | 410 | 480 | 560 | 700 | 850 | 1000 | |
| Test Speed | 6mm/s | 3mm/s | 3mm/s | 1.2mm/s | 0.8mm/s | 0.6mm/s | ||
| No-load Extension Speed | 4.5mm/s | 2.3mm/s | 10mm/s | 4.4mm/s | 3mm/s | 2.4mm/s | ||
| No-load Recovery Speed | 6mm/s | 3mm/s | 14mm/s | 5.8mm/s | 3.7mm/s | 3mm/s | ||
| Fuel Tank Capacity | 120L | 120L | 180L | 180L | 240L | 240L | ||
| Motor Power | 4KW | 4KW | 5.5KW+4KW | 5.5KW+4KW | 5.5KW+4KW | 5.5KW+4KW | ||
| Frequency | 50HZ | 50HZ | 50HZ | 50HZ | 50HZ | 50HZ | ||
| Voltage | 380V | 380V | 380V | 380V | 380V | 380V | ||
| Voltage and Freuenty can be customized | ||||||||
| Software Language | CHINESE&ENGLISH OR CUSTOMISED | |||||||
