Heat-Sealing Machine for Sterilization Roll

Main characteristics

Auto-control function, continuous operation; subsitution of manual sealing machine;

Temperature controlled by a microcomputer, accuracy 士1% ， working temperature range 60~220℃

Fast heating, 40 seconds required from room temperature to 180℃

Adjustable fixed-force system, suitable for sealing paper-plastic bags,3D paper-plastic bags and

paper-paper bags;

Advanced flat ceramic heating components, high-temperature stability, long life expectancy and high heat efficiency

Specification

Sealing speed 10m/min; Automatic controlled by sensor. Power: 500W

Seal width 12mm; Voltage: 220V  5OHz(optional)

Seal strength meets YY/T0698.5-2009 requirement;Dimension: 482x242x157(mm)

Seal margin: 0~35mm adjustable; Weight: 12kg

STERIVIC Medical Co.Ltd is a comprehensive export company, integrated in research and development, production and sales. As a leading sterilization packaging products manufacurer, it covers an area of 8 acres, construction area of 14,200 square meters, and has the first intelligent ISO Class 8 cleanroom workshop 3,000 square meters in the same line of domestic industry. With cutting-edge hardware and software facilities, we become the 2^nd largest professional manufacturer in China. Founded in 2014, Our company mainly focus on three product series: sterilization packagaing pouch&roll, medical wrapping crepe paper and nonwovens fabric wraps, sterilization control products. Two factories with 53 advanced production lines work together, export to more than 80 countries and regions globally. Our company obtained the TUV ISO9001 and ISO13485 international quality management system certification, disinfection product production license, Class 100,000 (i.e. ISO Class 8) workshop certification and other certificates. Products series dedicated to hospitals, central sterile supply department, dental clinics, clinical facilities and sterilization centers. Meanwhile, our company can provide superior quality medical sterilization packaging, medical dialyzing paper, medical flexible composite film for medical device equipment manufacturers as well as other series of industry solutions.
