High Quality Factory price HBCS40 Diesel Small Truck Mounted Concrete Line Pump

ID:21101263537

Category: Manufacturing & Processing Machinery Engineering & Construction Machinery

FOB Price:US$ 34375.000 / Set(s)

MOQ:1.00 Set(s)

Product Keywords:

Concrete Line PumpTruck Concrete Line Pumpsmall diesel concrete pumptrailer concrete line pumpline pump concretestationary concrete line pumpconcrete pump truckconcrete pump truck mountedcement concrete pumps truckchina concrete pump truck

Payment Method:

L/CT/TD/PWestern UnionPaypalMoney GramOthers

Product Category

Manufacturing & Processing Machinery > Engineering & Construction Machinery

Trademark

MINLE

Product Package

Small concrete pump in nude package, Parts and tools in carton/iron package. One 20GP for one set, one 40GP for two sets.

Specification

30m3-90m3

Place of Origin

CHINA

Port

Qingdao

High Quality Factory price HBCS40 Diesel Small Truck Mounted Concrete Line Pump

sara mobile/wechat/imo/whatsapp is 86-15866001919

mobile/wechat/whatsapp 86-15866001919

Choose MINLE as partner,let us make every effort to support your custruction works!

concrete Line pump, also called truck mounted concrete pump, is the concrete pump mounted on the truck for flexible movement and high pressure concrete pumping to the construction place, it provides both the pump truck and the trailer concrete pump advantages.

Parameters of concrete Line pump :

Item	HBCS40
Max Theoretical Concrete Output (m3/h)	40
Max Concrete outlet Pressure (Mpa)	10
Concrete slump (mm)	120-230
Power (KW)	Diesel motor 78
Speed (r/min)	2200
Aggregate size	gravel≤40
Concrete Cylinder Diameter (mm)	180/1000
Hydraulic Oil Tank Capacity (L)	200
Hopper Capacity (m3)	0.4
Filling Height (mm)	1250
Max Theoretical Conveying Distance (vertical Height/Horizontal Distance) (m)	150/500
pipe cleaning mode	washing
Overall Dimension (mm)	750022002600
Total Weight (kg)	11870
