Grinding head movable horizontal shaft moment table surface grinder

This series of machine tools adopts the movable structure of the grinding head and uses the periphery of the grinding wheel to grind the surface of the workpiece. It is suitable for grinding the plane of various parts in the industries of machinery manufacturing, automobiles, molds, and measuring tools.

Features:

●The bed is integrally cast, the whole machine has good rigidity, and the operation is stable and reliable.

●The column is placed on the right side of the machine tool, and the force is reasonable, and the coolant is not easy to splash on the electric cabinet and button station to ensure electrical safety.

●The longitudinal movement of the worktable is hydraulically driven, with stepless speed regulation.

●The horizontal guide rail of the carriage adopts a steel guide rail structure, which has good wear resistance and stable accuracy.

●The grinding wheel spindle is driven by an external low-vibration motor, which runs smoothly.

●The bed and worktable guide rail adopt continuous automatic lubrication, and the column, carriage and grinding head guide rail adopt inching motion lubrication, which effectively prevents the guide rail from losing oil and straining.

●W series adopts external hydraulic station, oil temperature is controllable, fuel-saving and environmentally friendly, and the thermal deformation of the machine tool is small.
