Vertical column movable horizontal shaft moment table surface grinder

This series of machine tools is independently developed by the company. It adopts a movable column structure and uses the periphery or end face of the grinding wheel to grind the surface of the workpiece. It is suitable for grinding the plane and side of various parts in machinery manufacturing, automobiles, molds, and measuring tools. side.

Features:

● Column mobile structure layout, stable accuracy.

●The vertical lifting of the grinding head and the lateral movement of the column adopt digital instruments (CK series adopts a program-controlled system) to control a servo motor to drive a precision ball screw drive. It is equipped with a fixed electronic hand wheel and has manual and automatic grinding functions.

●The longitudinal movement of the worktable is hydraulically driven, and the proportional control valve is steplessly adjusted to ensure stable operation.

●The longitudinal guide rail of the worktable and the vertical guide rail of the grinding head are pasted with PTFE soft tape, which has good abrasion resistance and high feed sensitivity.

●The bed and worktable guide rails adopt continuous automatic lubrication. The column and its movable base guide rails and ball screws can be programmed to achieve intermittent lubrication, which can effectively prevent oil loss and strain.

●The grinding head spindle adopts integral inner column outer tapered sliding bearing, which has strong structural rigidity, large bearing capacity, good grinding surface quality of the workpiece, and convenient maintenance.

●The grinding wheel spindle is driven by an external low-vibration motor, which runs smoothly.

●External hydraulic station, oil temperature controllable, fuel-saving and environmentally friendly, with small thermal deformation of the machine tool.
