CLOUMN WAIST-MOBILE CNC CREEP FEED PROFILE GRINDING MACHINES

This series of slow-feed CNC powerful forming grinders are produced by relying on the technology of European industrial powers and can replace imports. It is widely used in the manufacturing industries of aircraft, ships, automobiles (locomotives), hydraulic components and other manufacturing industries. Engines, turbine blades, fir tree roots or cleat grooves, steering nut teeth, thread rolling board blades, cycloid pump rotors and other complex mechanical parts Surface forming and grinding.

Features:

●The unique anti-collision grinding head structure has been authorized by the national invention patent .

●Mid-waist column moving structure, horizontal guide rails are placed on both sides of the middle of the column, running smoothly and feeding sensitively.

●With forming and surface grinding processing functions, high working accuracy, positioning accuracy and repeat positioning accuracy.

●Innovative design and advanced technology. The X, Y, and Z axes all adopt linear guides and ball screws, and the X axis adopts a floating nut structureauthorized by the national invention patent, which has good assembly technology.

●The standard configuration of the CNC system is the new-generation brand from Taiwan, and other brands such as Siemens and Fanuc can also be selected, which can individually control or link longitudinal movement, lateral feed, vertical feed, grinding wheel spindle and dresser spindle; Functions such as linear interpolation and circular interpolation can realize automatic cyclic grinding.

●Apply a variety of shaping and dressing technologies. The grinding wheel can be shaped with diamond rollers or diamond pens or diamond discs through the Y and Z two-axis linkage trimming, with high dressing accuracy.
