ID:21102265026
Auto,Parts & Accessories Truck & Accessories
MOQ:4.00 Set(s)
truckslight trucksdumper trucks dumpers
L/CT/TD/P
Shandong shifeng Group was established on 18th May, 1993.The group covers an area of 333 hectares, its total assets is 6 billion RMB and more than10,000 employees. The leading products includes 3-wheel trucks, light trucks, tractors, engines, scaffolding systems and nylon products in 5 different factories.
★Shifeng Central science-tech research center: is thetechnique developing center of Shandong province. There are 13 technology institutes and 2500 technicians. It is biggest CAD base in Agricultural automobiles industry, and also have 1000 patents;
★ All the produtcs are made strictly according to ISO9001 standards. Our 700 QC staff ensure that our products will be qualified by the standard;
★1500 Distribution spots and 2000 Suppliers: It has opened guarantee business among An-gang Steel Group and Bank of China, co-operate with Shanghai Baogang Steel Group and SINO Petrochemicals Group. A whole country supplying and marketing network has come into being. We exported our products to more than 50 countries in Africa, Europe and America. For example, USA, Mexico, Indonesia, Pakistan, Bangladesh and Albania, etc.
★The sales volume of the fittings marketing company of Shifeng Group amounts to RMB 500 million yearly, it is the biggest agricultural vehicle fittings collection and distribution center in China.
★Pressing, Welding, Painting and Assembling technics can reach up to Automobiles’ Producing request, Casting and Heat treatment are one-up in Chinese same industry.
★production capacity per year: 3 wheel trucks 1.3 million units, Light Trucks 80 Thousand units, Diesel Engines 1.5 Million sets, Tractors 300 Thousand units, scaffolding system 3000 Thousand Tons , nylon products 100 Thousand Tons
1.famouce brand diesel engine with high torque,much more Power;
2.more loading capacity;
3.lower fuel consumption,much more economic;
4.easily operation and maintenance: Spare parts and services are easily managed.
5.technical supporting and modification according to customers' requirements are available.
| Brand | SHIFENG | |
| Item | MINI TRUCK | |
| Cabin | Fengyun cabin | |
| whole vehicel main demensions | Overall dimensions (L*W*H)mm | 5180*1717*2115 |
| Dimensions of cargo body (L*W*H)mm | 3050*1630*400 | |
| Driving type | 4×2 | |
| Wheel base | 2700 | |
| Wheel track(F/R)mm | 1440/1315 | |
| Min groud clearance (mm) | 400 | |
| Weight data | Curb weight (kg) | 2380 |
| Rated payload(kg) | 2500-3000 | |
| Person in cab (persons) | 2 | |
| whole vehicle main performance | Max.speed(km/h) | 90 |
| Max.slope of climb(%) | 25 | |
| Min.turning radius (m) | 5.5 | |
| Engine | Engine type | 4A2-82C50 |
| Brand | QUANCHAI | |
| Fuel injection equipment | Common-rail with EDC + SCR | |
| Emission standard | Euro5 | |
| Displacement (L) | 2.27 | |
| Rated power (KW) | 60 | |
| Max torque (N.m/rpm) | 245 /1600---2400 | |
| Gear box | Model | MT78HQ |
| Type | Manual, 10+2 | |
| Steering gear type | Merchanical | |
| Brake system | Service brake and boosting type | oil brake |
| Parking brake | Central drum brake | |
| Auxiliary brake | N/A | |
| Wheels and tyre size | 6.00-15/6.00-15 | |
| Electric system | Rated voltage | 24V |
| Battery | 100Ah | |
