No.

Items

Parameter

1

Product Model

VC-51.2-102.6-Y (26650-3.2V3800mAh-16S27P)

2

Normal Voltage

51.2V

3

Rated Capacity

102.6Ah(C5)

4

Min Capacity

97.5 Ah(C5)

5

Energy

About 5153.12Wh

6

Internal Resistance

≤45mΩ

7

Size

（550±5）mm *（482±4）mm *（177±2）mm

8

weight

44±1.0kg

9

Shell material

iron

10

communication

RS485

11

Charge Voltage

57.6±0.2V

12

Standard Cutoff Voltage

about 40V

13

Charge Current

≤15A

14

Charging cut-off current

1.026A~2.052A

15

Discharge Current

Normal Current

≤100A

16

Passive Protection

Over charge protection, Over discharge protection, Temperature protection, Balanced function

17

Charge Connector

TBD

18

Discharge Connector

TBD

19

Charge Retention

After charging according to standard 3.2, placing the battery for 28 days under the standard test

conditions, then discharge it under standard 3.3, and the charge retention rate is ≥80%.

20

Cycle time

The cycle life is not less than 2000, the capacity retention rate is ≥80%. (Charging according to

3.2 standard, leaving 0.5~1h; discharging according to 3.3 standard, leaving 0.5~1h, counting 1 cycle time).
