Item: Linear actuator
Housing material: Aluminum
Motor Type: Permanent magnet brushed DC motor
Input voltage: 12V/24V/36V/48V
Drive system type: Gear
Nut material: Brass
Rated load: 1200N
Max stroke: 600mm
Feedback signal: Optional (potentiometer)
Finish: Power Coated
Duty cycle: 25%
Limit switches: Built-in
Newton (N) to Pound (lbs)
Newton | 1200N | 1000N | 800N | 500N | 200N | 100N |
LBS | 264 | 220 | 176 | 110 | 44 | 22 |
L.min means the length when linear actuator 100% fully retracts, meanwhile, it will touch the tail limited switch, stop automatically, very safe.
Stroke means the movement length of linear actuator.
L.max means the length when linear actuator 100% fully extends, meanwhile, it will touch the head limited switch, stop automatically, very safe.
It is a linear actuator which is small in size, robust, waterproof and easy to install.
Each linear actuator comes with 2 wires (positive and negative), no external limit switches and mounting holes on each end.
Feature of linear actuator
l Small size
l Light weight
l Waterproof
l Easy to install
l Stable performance
l Potentiometer feedback
l Customize stroke
l Warranty 1 year
