Mechanical Liner Hanger Used in Oilfield

Application:

Mechanical suspension could be used for hanging the bottom of the need to cement and non-need to cement cementing the pipe tail. mechanical suspension via a raise, rotate out of type J keyway means hanging seat

Features:
 1. Adaption high quality alloy steel, high mechanical strength , the weight of hoisting a large tail pipe
 2. Through the mention, forward set free mechanically link to set down, easy to operate can be used for vertical wells deviate wells and more complex of tools used in combination completions
 3. Rubber plugs locking seat are designed with a locking mechanism and has a good drill ability
 4. Seal with the wick can be made into tools
 5. The seal assembly using multiple sets of seals with two-way sealing function and good sealing effect
 6. The upper and lower hanger rings are fitted with righting, we can make sure hanger center ,improve the efficiency of hanging seat, but also can protect the kava.
 7. No need to buckle down and find the point , as long as hanger at 5-10tons or pressure is transferred, you can easily fall open .
