Medical equipment TFT color LCD portable 3 channel ecg monitor ECG300G

ID:24122094395

Category: Medical & Health & Beauty Medical Devices

FOB Price:US$ 285.000 / Set(s)

MOQ:1.00 Set(s)

Product Keywords:

ecg monitorecg monitor portableportable ecgelectrocardiogramecg machine 3 channelekg machine portableelectrocardiogram machineecg machine portableelectrocardiography ecgportable ecg device

Payment Method:

L/CT/TD/PWestern UnionPaypalMoney GramOthers

Product Category

Medical & Health & Beauty > Medical Devices

Trademark

OEM

Product Package

carton

Specification

ECG300G

Place of Origin

China

Port

Tianjin xingang

Product Description

Introduction:

WJ-ECG300G is an Electrocardiograph which can collect 12-lead ECG signal and print waveform by the thermal printing system. It features in, recording and displaying ECG waveform in AUTO/Manual mode, measuring and diagnosing ECG waveform parameters automatically, prompting for “Lead off” and “Lack of paper”, multi-language interface, AC/DC, selecting any rhythm lead, case database management.

Function:

1)Sync collection for 12-lead ECG, adopt digital signal processing technology and get high-quality ECG waveform via power frequency filter, baseline filter and EMG filter of ECG signal.
2)Display of 3/6/12-lead ECG, print mode, sensitivity, paper speed and filter state, etc. on one screen, convenient for
contrastively diagnosing.
3)Multiply printing modes and formats, including manual, auto 4×3, auto 3×4+1, auto 3×4, auto 2×6+1, auto 2×6, auto 3-2+1, auto 3-2, auto 1×12+1, auto 1×12, rhythm 4, rhythm 3 and rhythm 2, etc. Waveform length printed can be adjusted, and with time print function, which meets different requirements.
4)With the functions of auto-analysis and auto-diagnosis for routine ECG parameters, provide measurement results and
auto-diagnosis conclusion for HR, P-R interval, P Duration, QRS Duration, T Duration, Q-T interval, Q-Tc, P Axis, QRS Axis, T
Axis, R(V5), S(V1), R(V5)+S(V1), etc. which reduces the doctor’s burden.
5)Built-in memory stores up to 1000 cases, convenient for case review and statistic.
6)Multi-language(Chinese, English, Spanish, Turkish, Polish, Italian, French, German, Portuguese, Kazakstan, Russian, Ukrainian, Serbian and Slovenian) interface and report.

Product name	WJ-ECG300G ECG machine
Frequency response	0.05Hz ~ 150Hz(-3dB~+0.4dB)
Sensitivity	2.5, 5, 10, 20, 40 mm/mV ±5%, standard sensitivity: 10mm/mV±2%
Safety classification	class I, type CF and defibrillation-proof applied part
Auto record	set record according to auto record format and mode, automatically switching leads, measuring and analyzing.
Rhythm record	set record according to rhythm record format and mode, automatically measuring and analyzing.
Manual record	set record according to record format, manually switching leads.
Measurement parameters	HR, P-R interval, P Duration, QRS Duration, T Duration, Q-T interval, Q-Tc, P Axis, QRS Axis, T Axis, R(V5), S(V1), R(V5)+S(V1)
Fuse specification	two AC time lag fuse(φ5×20mm), T1.6AL250V
Optional:	ECG-Sync software+USB cable ECG electrode Bag Conductive gel
